VFD7A5ME21AFNAA: Delta Built-in EMC Filter 1.5kW Drive
Technical Specifications of VFD7A5ME21AFNAA Delta Built-in EMC Filter 1.5kW Drive:
| Spec | Value |
|---|---|
| Series Name | ME300 |
| Input Voltage Frequency | 230V, Single-phase AC, 200V~240V (-15% ~ + 10%), 50 / 60Hz |
| Applicable Motor Output ( kW) | 1.5 kW |
| Applicable Motor Output (HP) | 2 HP |
| Output Frequency | 0.00 ~ 599.00 Hz (±0.1%) |
Delta Built-in EMC Filter 1.5kW Drive VFD7A5ME21AFNAA Technical specifications:
| Specification | Value |
|---|---|
| Series Name | ME300 |
| Input Voltage / Frequency | 230V, Single-phase AC, 200V~240V (-15% ~ + 10%), 50 / 60Hz |
| Applicable Motor Output ( kW) | 1.5 kW |
| Applicable Motor Output (HP) | 2 HP |
| Heavy Duty Rated Output Current (A) | 7.5 A |
| Normal Duty Rated Output Current (A) | 8.5 A |
| Cooling Method | Fan cooling |
| IP Level | IP20 |
| EMC Filter | Built-In |
| Safe Torque Off (STO) | None |
| Model Type | Standard model |
| Braking Chopper | Built-in |
| Output Frequency | 0.00 ~ 599.00 Hz (±0.1%) |
| MODBUS COM | Built-in |
| Control Methods | V/F, SVC |
| Size: W × H (mm) | 87 x 157 |
| Size: D (mm) | 163 |
| Net Weight | 1 |
Obtain a Quote for Delta Built-in EMC Filter 1.5kW Drive, VFD7A5ME21AFNAA at economical prices. Specifications Overview for VFD7A5ME21AFNAA reveals Model Type is Standard model, None Safe Torque Off (STO), Built-In EMC Filter & Built-in Braking Chopper. It also includes 1.5 kW, 2 HP & 7.5 A. Take the First Step with a Quote for your requirement of Delta Built-in EMC Filter 1.5kW Drive. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
