Koino IPX-2D30-10A1S - Rectangular Inductive Proximity Sensor
Technical Specifications of Koino Rectangular Inductive Proximity Sensor IPX-2D30-10A1S:
Spec | Value |
---|
Sensing Distance | 10.0 mm ±10% |
Connection Method | Pre-wired |
Operation Mode | NO |
Size | 30 mm |
Koino IPX-2D30-10A1S Rectangular Inductive Proximity Sensor Technical Specifications
Specification | Value |
---|
Sensor Type | DC 2-wire Inductive Proximity Sensor |
Shape | Rectangular |
Size | 30 mm |
Sensing Distance | 10.0 mm ±10% |
Set Distance | 0~8.0mm |
Connection Method | Pre-wired |
Operation Mode | NO |
Polarity | Polar |
Response Frequency | 250Hz |
Power Supply Voltage | 10~30VDC |
Rated Operating Voltage | 24VDC |
Detectable Object | Ferrous metal |
Differential Travel | max. 10% of sensing distance |
Control Output | 3~100mA |
Leakage current | 0.7mA max. |
Indicator | Red LED |
Protection Circuits | Surge suppressor, load short-circuit protect, |
Ambient Temperature (Operating) | -25° C~+70° C |
Ambient Temperature (Storage) | -30° C~+80° C |
Ambient Humidity | 35~95%RH |
Insulation Resistance | Minimum 100MΩ (500VDC) |
Dielectric Strength | 1,500VAC 50/60Hz for 1min |
Vibration Resistance | 10~55Hz double amplitude 1.5mm (at X, Y and Z axis) for 2hrs |
Shock Resistance | 50G |
Degree of Protection | IP67 |
Body Material | Nickel-Plated Brass |
Sensing Surface Material | PBT |
