Legrand Fuse | Catridge Fuse Switch

IndMALL Automation offers Legrand Fuse series. Our selection features the reliable HRC blade type cartridge fuses, each tailored for specific electrical protection needs. These fuses range from 25 A to 50 A, all designed with visual indicators for easy status checks. Legrand fuses are recognized for their compliance with EN 60269-1, IEC 60269-1, 2, and VDE 0636-1, ensuring global standards are met. Each fuse supports 500 Volts AC and boasts a significant breaking capacity of 120000 Amps. The compact design measures 78.5 mm in width, 60 mm in height, and 30 mm in depth, facilitating easy integration into various setups. These fuses are essential for robust protection in industrial applications, safeguarding both equipment and operations.

Legrand Fuse: type aM 22 X 58 - 25 A - w indicator

Product Type: HRC blade type cartridge fuse, cylindrical aM 22 X 58.
Current Rating: 25 A, with visual indicator.
Compliance: Meets EN 60269-1, IEC 60269-1, 2, and VDE 0636-1.
Voltage Specifications: 500 Volts AC; Breaking capacity of 120000 Amps.
Physical Dimensions: Width: 78.5 mm, Height: 60 mm, Depth: 30 mm.

Legrand Fuse Switch: cartridge fuse - cylindrical type aM 22 X 58 - 32 A - w indicator

Product Type: HRC blade type cartridge fuse, cylindrical aM 22 X 58.
Current Rating: 32 A with visual indicator.
Standards Compliance: Meets EN 60269-1, IEC 60269-1, 2, and VDE 0636-1.
Voltage Specifications: 500 Volts AC; Breaking capacity of 120000 Amps.

Legrand Fuse Box: fuse - cylindrical type aM 22 X 58 - 40 A - w indicator

Product Type: HRC blade type cartridge fuse, cylindrical aM 22 X 58.
Current Rating: 40 A with visual indicator.
Standards Compliance: Compliant with EN 60269-1, IEC 60269-1, 2, and VDE 0636-1.
Voltage Specifications: Rated at 500 Volts AC; Breaking capacity of 120000 Amps.

Legrand Cartridge Fuse: cartridge fuse - cylindrical type aM 22 X 58 - 50 A - w indicator

Product Type: HRC blade type cartridge fuse, cylindrical aM 22 X 58.
Current Rating: 50 A with visual indicator.
Standards Compliance: Compliant with EN 60269-1, IEC 60269-1, 2, and VDE 0636-1.
Voltage Specifications: Rated at 500 Volts AC; Breaking capacity of 120000 Amps.

Fuse Legrand: cartridge fuse - type gG - size 00 - 25 A - with indicator

Product Type: HRC blade type cartridge fuse.
Category: Type gG, suitable for general application, including cable and equipment protection.
Size and Rating: Size 00, rated at 25 A.
Indicator Feature: Equipped with a top fuse status indicator for visual inspection.
Voltage Ratings:
AC rating: 500 Volts.
DC rating: 48 Volts.
Breaking Capacity: 120000 Amps, ensuring robust fault handling.
Compliance: Conforms to IEC 60269-2 standards.
Safety Features: Recommended use of terminal shields and fuse covers for protection against accidental contacts.

At IndMALL Automation, we proudly feature a robust selection of Legrand Fuses. Our inventory includes various types of Legrand Cartridge Fuses, specifically designed for diverse industrial applications. Each fuse guarantees compliance with international standards such as EN 60269-1 and IEC 60269-1. Notably, our Legrand Fuse Boxes and Legrand Fuse Switches provide reliable protection with ratings up to 160 A. These devices are essential for maintaining safety and efficiency in power management systems. Available in sizes ranging from 22 X 58 to size 00, they support installations requiring high breaking capacities of 120000 Amps. Explore our Legrand Fuse offerings to ensure superior electrical protection in your industrial setups.

Frequently Asked Questions

What size is a HRC fuse?

HRC fuse sizes vary primarily based on voltage ratings. Fuses with higher voltage ratings typically feature longer bodies. This design helps minimize the likelihood of arcing within the fuse, enhancing safety and efficiency.

What is the use of HRC fuse?

HRC fuses are primarily used for short circuit protection. They are designed to carry heavy short circuit currents over a specified period of time. This capability ensures the safety and reliability of electrical systems by preventing damage due to excessive current flow.

What is the full form of HRC switch?

The full form of HRC in relation to switches is “High Rupturing Capacity.” HRC fuses are designed to safely interrupt short circuit currents within a set period, preventing potential damage by stopping the flow of excessive current through the circuit.
