Leuze CRT 20B M/P-60-001-S12 | 50109597
Technical Specifications of Leuze CRT 20B M/P-60-001-S12 50109597:
| Spec | Value |
|---|---|
| Design | Cubic |
| Dimensions | 30 mm x 80 mm x 53 mm |
| Application | Detection of one color |
| Light Source | LED, RGB |
Leuze Detection of One Color Sensor CRT 20B M/P-60-001-S12, 50109597 Technical Specifications:
| Specification | Value |
|---|---|
| Design | Cubic |
| Thread Size | M12 |
| Dimension | 30 mm x 80 mm x 53 mm |
| Application | Detection of one color |
| Operating range | 51 ... 69 mm |
| Light source | LED, RGB |
| Light spot size [at sensor distance] | 13 mm [60 mm] |
| Light spot orientation | Round |
| Type of light spot geometry | Round |
| Supply voltage UB | 10 ... 30 V, DC |
| Number of teach inputs | 1 Piece(s) |
| Number of digital switching outputs | 1 Piece(s) |
| Switching output 1 | Transistor, PNP |
| Switching output 2 | - |
| Switching output 3 | - |
| Switching frequency | 6,000 Hz |
| Type of connection | Connector |
| No. of Pin | 5 -pin |
| Housing material | Metal |
| Plastic housing | - |
| Ambient temperature, operation | -10 ... 55 °C |
| Degree of protection | IP 67 |
Give Us a Call for Leuze Detection of One Color Sensor CRT 20B M/P-60-001-S12 50109597 at lowest pricing. The Main Technical Parameters of CRT 20B M/P-60-001-S12 are Cubic Design, 30 mm x 80 mm x 53 mm Dimensions, 51 ... 69 mm Operating Range, LED, RGB Light Source, 13 mm [60 mm] Light Spot Size, Transistor, PNP Switching Output 6,000 Hz Switching Frequency, Connector, M12 Thread size, Metal Housing material, IP 67 degree of protection. Elevate Your Project with a Quote for your requirement of Leuze Detection of One Color Sensor.
