IS 180PP/22-50N-TB.4: 50133405 - Leuze 50mm Sensing Inductive Switch
Technical Specifications of Leuze 50mm Sensing Inductive Switch IS 180PP/22-50N-TB.4:
| Spec | Value |
|---|---|
| Sensing Distance | 50 mm |
| Switching Output | Transistor, NPN |
| TYpe of Installation | Non-embedded |
| Type of Connection | Terminal |
Leuze 50mm Sensing Inductive Switch IS 180PP/22-50N-TB.4, 50133405 Technical Specifications:
| Specification | Value |
|---|---|
| Series | 180 |
| Sensing Distance | 50 mm |
| Supply Voltage | 10 ... 30 V, DC |
| Number of digital switching outputs | 2 Piece(s) |
| Switching Current | 200 mA max. |
| Residual Current | 0.01 mA max. |
| Voltage drop | ≤ 2 V |
| O/P 1: Switching Output | Transistor, NPN |
| O/P 1: Switching Principle | NO (normally open) |
| O/P 2: Switching Output | Transistor, NPN |
| O/P 2: Switching Principle | NC (normally closed) |
| Switching frequency, max. | 100 Hz |
| Number of connections | 1 Piece(s) |
| Connection Function | Signal OUT Voltage supply |
| Type of Connection | Terminal |
| Number of conductors or Pins | 4 -pin |
| Design | Cubic |
| Dimension (Ø x L) | 40 mm x 80 mm x 80 mm |
| Type of installation | Non-embedded |
| Housing material | Plastic |
| Sensing face material | Plastic, Polybutylene (PBT) |
| Housing color | Black, Red, RAL 3000 |
| Standard measuring plate | 150 x 150 mm², Fe360 |
| Number of LEDs | 2 Piece(s) |
| Ambient temperature | -25 ... 70 °C |
| Degree of protection | IP 67 |
Get A Quote for Leuze 50mm Sensing Inductive Switch IS 180PP/22-50N-TB.4 part no: 50133405 at the best price. Here are the brief Technical Specifications of IS 180PP/22-50N-TB.4, 50133405 feature 180 series, 50 mm Sensing, 10 ... 30 V, DC power supply, 2 Piece(s) digital switching output, 200 mA max. current, Transistor, NPN , NO (normally open) output 1, Transistor, NPN , NC (normally closed) output 2, 100 Hz, 1 Piece(s) Connection, Terminal, 4 -pin, Cubic, 40 mm x 80 mm x 80 mm dimentions, Non-embedded, Plastic, Polybutylene (PBT), 2 Piece(s) LEDs, Black, Red, RAL 3000 color, IP 67 degree of protection. It's Time to get a Quote for your requirement of Leuze 50mm Sensing Inductive Switch. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
