IS 218FM/4NO.5-5E0: 50128170 - Leuze PUR Cable Embedded Switch
Technical Specifications of Leuze PUR Cable Embedded Switch IS 218FM/4NO.5-5E0:
| Spec | Value |
|---|---|
| Sensing Distance | 5 mm |
| Switching Output | Transistor, PNP |
| TYpe of Installation | Embedded |
| Type of Connection | PVC Cable, 2,000m Length |
Leuze PUR Cable Embedded Switch IS 218FM/4NO.5-5E0, 50128170 Technical Specifications:
| Specification | Value |
|---|---|
| Series | 218 |
| Sensing Distance | 5 mm |
| Supply Voltage | 10 ... 30 V, DC |
| Number of digital switching outputs | 1 Piece(s) |
| Switching Current | 200 mA |
| Residual Current | 0.01 mA |
| Voltage drop | ≤ 2 V |
| O/P 1: Switching Output | Transistor, PNP |
| O/P 1: Switching Principle | NO (normally open) |
| O/P 2: Switching Output | - |
| O/P 2: Switching Principle | - |
| Switching frequency, max. | 100 Hz |
| Number of connections | 1 Piece(s) |
| Connection Function | Signal OUT Voltage supply |
| Type of Connection | PVC Cable, 2,000m Length |
| Number of conductors or Pins | 3 -wire |
| Design | Cylindrical |
| Dimension (Ø x L) | 18 mm x 51 mm |
| Type of installation | Embedded |
| Housing material | Stainless steel |
| Sensing face material | Stainless steel, AISI 305 |
| Housing color | Silver |
| Standard measuring plate | 18 x 18 mm², Fe360 |
| Number of LEDs | 1 Piece(s) |
| Ambient temperature | Operation: -25 ... 70 °C |
| Degree of protection | IP 68 IP 69K |
Call us for Leuze PUR Cable Embedded Switch IS 218FM/4NO.5-5E0 part no: 50128170 at the best rates. Technical Attributes of IS 218FM/4NO.5-5E0, 50128170 are218 series, 5 mm Sensing, 10 ... 30 V, DC power supply, 1 Piece(s) digital switching output, 200 mA current, Transistor, PNP , NO (normally open) output 1, - , - output 2, 100 Hz, 1 Piece(s) Connection, PVC Cable, 2,000m Length, 3 -wire, Cylindrical, 18 mm x 51 mm dimentions, Embedded, Stainless steel, AISI 305, 1 Piece(s) LEDs, Silver color, IP 68 IP 69K degree of protection.Unlock Exclusive Pricing with a Quote for your requirement of Leuze PUR Cable Embedded Switch. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
