LE22/4: 50140124 - Leuze Transistor PNP, Light Switch Through Beam Receiver Sensor

Spec	Value
Operating Principle	Throughbeam principle
Device Type	Receiver
Operating Range	0 ... 1 m
Switching Output	Transistor, PNP

Leuze Transistor PNP, Light Switch Through Beam Receiver Sensor LE22/4, 50140124 Technical Specifications:

Specification	Value
Series	22
Operating principle	Throughbeam principle
Device type	Receiver
Operating range	0 ... 1 m
Power Supply	11 ... 26 V, DC, Incl. residual ripple
Open-circuit current	-
Number of digital switching outputs	1 Piece(s)
Switching Output	Transistor, PNP
Switching Principle	Light switching
Switching frequency	-
Response time	0.5 ms
Readiness delay	100 ms
Connection Function	Signal IN Voltage supply
Type of Connection	2000 mm PVC Cable
Number of conductors or Pins	3 -wire
Dimension (W x H x L)	16.2 mm x 30 mm x 6.8 mm
Housing material	Plastic: PC-PBT
Lens cover material	Plastic
Housing color	Black
Type of display	LED
Ambient temperature	operation -25 ... 55 °C storage -25 ... 75 °C
Degree of protection	IP 67
Net weight	-

IndMALL Automation Dealing offers Leuze Transistor PNP, Light Switch Through Beam Receiver Sensor LE22/4 part no: 50140124 at unbeatable prices. The Main Technical Parameters of LE22/4, feature 22 series, Throughbeam principle , Receiver device, 11 ... 26 V, DC, Incl. residual ripple power supply, - current, 1 Piece(s) digital switching output, Transistor, PNP output, Light switching , - frequency, 2000 mm PVC Cable, 3 -wire , 16.2 mm x 30 mm x 6.8 mm dimensions, Black housing color, LED display, IP 67 degree of protection. Take the First Step with a Quote for your requirement of Leuze Transistor PNP, Light Switch Through Beam Receiver Sensor.

LE22/4: 50140124 - Leuze Transistor PNP, Light Switch Through Beam Receiver Sensor

Leuze Transistor PNP, Light Switch Through Beam Receiver Sensor LE22/4, 50140124 Technical Specifications:
