Leuze 0.33 ms Response Time Through Beam Receiver Sensor LE25C.1/2N-M12, 50139698 Technical Specifications:
Specification
Value
Series
25C
Operating principle
Throughbeam principle
Device type
Receiver
Operating range
0 ... 25 m
Power Supply
10 ... 30 V, DC, Incl. residual ripple
Open-circuit current
0 ... 20 mA
Number of digital switching outputs
2 Piece(s)
Switching Output
Transistor, NPN
Switching Principle
Light switching/Dark switching
Switching frequency
1,500 Hz
Response time
0.33 ms
Readiness delay
300 ms
Connection Function
Signal OUT
Voltage supply
Type of Connection
M12 Connector
Number of conductors or Pins
4 -pin
Dimension (W x H x L)
15 mm x 42.7 mm x 30 mm
Housing material
Plastic: ABS
Lens cover material
Plastic
Housing color
Red
Type of display
-
Ambient temperature
operation -40 ... 60 °C
storage -40 ... 70 °C
Degree of protection
IP 67, IP 69K
Net weight
22 g
IndMALL Automation Dealing offers Leuze 0.33 ms Response Time Through Beam Receiver Sensor LE25C.1/2N-M12 part no: 50139698 at unbeatable prices. The Main Technical Parameters of LE25C.1/2N-M12, feature 25C
series, Throughbeam principle
, Receiver device, 10 ... 30 V, DC, Incl. residual ripple power supply, 0 ... 20 mA current, 2 Piece(s)
digital switching output, Transistor, NPN output, Light switching/Dark switching, 1,500 Hz frequency, M12 Connector, 4 -pin, 15 mm x 42.7 mm x 30 mm
dimensions, Red housing color, IP 67, IP 69K degree of protection. Take the First Step with a Quote for your requirement of Leuze 0.33 ms Response Time Through Beam Receiver Sensor.
