LE46C.1/4P-200-M12: 50136148 - Leuze IP67, IP69K Degree of Protection Receiver Sensor

SpecValue
Operating PrincipleThroughbeam principle
Device TypeReceiver
Operating Range0.5 ... 120 m
Switching OutputTransistor, PNP

Leuze IP67, IP69K Degree of Protection Receiver Sensor LE46C.1/4P-200-M12, 50136148 Technical Specifications:

SpecificationValue
Series46C
Operating principleThroughbeam principle
Device typeReceiver
Operating range0.5 ... 120 m
Power Supply10 ... 30 V, DC, Incl. residual ripple
Open-circuit current0 ... 20 mA
Number of digital switching outputs2 Piece(s)
Switching OutputTransistor, PNP
Switching PrincipleLight switching/Dark switching
Switching frequency500 Hz
Response time1 ms
Readiness delay300 ms
Connection FunctionSignal OUT Voltage supply
Type of Connection200 mm PUR Cable with M12 Connector
Number of conductors or Pins4 -pin
Dimension (W x H x L)20.5 mm x 76.3 mm x 44 mm
Housing materialPlastic: PC-PBT
Lens cover materialPlastic / PMMA
Housing colorRed
Type of displayLED
Ambient temperatureoperation -40 ... 60 °C storage -40 ... 70 °C
Degree of protectionIP 67, IP 69K
Net weight65 g
Ask for the Pricing of Leuze IP67, IP69K Degree of Protection Receiver Sensor LE46C.1/4P-200-M12 part no: 50136148 at unbeatable prices. Detailed Specifications of LE46C.1/4P-200-M12, are 46C series, Throughbeam principle , Receiver device, 10 ... 30 V, DC, Incl. residual ripple power supply, 0 ... 20 mA current, 2 Piece(s) digital switching output, Transistor, PNP output, Light switching/Dark switching, 500 Hz frequency, 200 mm PUR Cable with M12 Connector, 4 -pin, 20.5 mm x 76.3 mm x 44 mm dimensions, Red housing color, LED display, IP 67, IP 69K degree of protection. Now's the Time to Secure a Quote for your requirement of Leuze IP67, IP69K Degree of Protection Receiver Sensor.
