LS23/XX: 50138444 - Leuze Plastic/PMMA Lens Cover Material Sensor
Technical Specifications of Leuze Plastic/PMMA Lens Cover Material Sensor LS23/XX 50138444:
| Spec | Value |
|---|---|
| Operating Range | 0 ... 10 m |
| Dimension | 11.4 mm x 34.2 mm x 18.3 mm |
| Type of Connection | PUR Cable, 2m Length |
| Connection Function | Voltage supply |
Leuze Plastic/PMMA Lens Cover Material Sensor LS23/XX, 50138444 Technical Specifications:
| Specification | Value |
|---|---|
| Series | 23 |
| Operating principle | Throughbeam principle |
| Device type | Transmitter |
| Operating range | 0 ... 10 m |
| Light source | LED, Red |
| Wavelength | 645 nm |
| Power Supply | 10 ... 30 V, DC |
| Open-circuit current | 0 ... 15 mA |
| Readiness delay | 300 ms |
| Connection Function | Voltage supply |
| Type of Connection | PUR Cable, 2m Length |
| Number of conductors or Pins | 3-wire |
| Dimension | 11.4 mm x 34.2 mm x 18.3 mm |
| Housing material | Plastic: PC-ABS |
| Lens cover material | Plastic / PMMA |
| Housing color | Black, Red |
| Type of display | LED |
| Ambient temperature | Operation: -40 ... 60 °C Storage: -40 ... 70 °C |
| Degree of protection | IP 67 |
| Net weight | 50 g |
IndMALL Offers Leuze Plastic/PMMA Lens Cover Material Sensor LS23/XX part no: 50138444 at the lowest pricing. Technical Specs Summary of LS23/XX, 50138444 includes 23 series, Throughbeam, Transmitter device, 0 ... 10 m operating range, LED, Red light source, 645 nm wavelength, 10 ... 30 V, DC power supply, 0 ... 15 mA current, PUR Cable, 2m Length, 3-wire, 11.4 mm x 34.2 mm x 18.3 mm dimensions, Black, Red housing color, LED display, IP 67 degree of protection. Now's the Time to Secure a Quote for your requirement of Leuze Plastic/PMMA Lens Cover Material Sensor. We're committed to offering more favorable pricing and more responsive support than other Traders.
