LS23/XX-M8: 50138491 - Leuze 18.3 mm Length Throughbeam Sensor
Technical Specifications of Leuze 18.3 mm Length Throughbeam Sensor LS23/XX-M8 50138491:
| Spec | Value |
|---|---|
| Operating Range | 0 ... 10 m |
| Dimension | 11.4 mm x 34.2 mm x 18.3 mm |
| Type of Connection | M8 Connector |
| Connection Function | Voltage supply |
Leuze 18.3 mm Length Throughbeam Sensor LS23/XX-M8, 50138491 Technical Specifications:
| Specification | Value |
|---|---|
| Series | 23 |
| Operating principle | Throughbeam principle |
| Device type | Transmitter |
| Operating range | 0 ... 10 m |
| Light source | LED, Red |
| Wavelength | 645 nm |
| Power Supply | 10 ... 30 V, DC |
| Open-circuit current | 0 ... 15 mA |
| Readiness delay | 300 ms |
| Connection Function | Voltage supply |
| Type of Connection | M8 Connector |
| Number of conductors or Pins | 4 -pin |
| Dimension | 11.4 mm x 34.2 mm x 18.3 mm |
| Housing material | Plastic: PC-ABS |
| Lens cover material | Plastic / PMMA |
| Housing color | Black, Red |
| Type of display | LED |
| Ambient temperature | Operation: -40 ... 60 °C Storage: -40 ... 70 °C |
| Degree of protection | IP 67 |
| Net weight | 20 g |
Ask for the Pricing of Leuze 18.3 mm Length Throughbeam Sensor LS23/XX-M8 part no: 50138491 at unbeatable prices. Detailed Specifications of LS23/XX-M8, 50138491 feature 23 series, Throughbeam, Transmitter device, 0 ... 10 m operating range, LED, Red light source, 645 nm wavelength, 10 ... 30 V, DC power supply, 0 ... 15 mA current, M8 Connector, 4 -pin, 11.4 mm x 34.2 mm x 18.3 mm dimensions, Black, Red housing color, LED display, IP 67 degree of protection. Now's the Time to Secure a Quote for your requirement of Leuze 18.3 mm Length Throughbeam Sensor. We're committed to offering more favorable pricing and more responsive support than other Traders.
