LS25CI.XR1/XX: 50147917 - Leuze 860nm Wavelength Transmitter Sensor
Technical Specifications of Leuze 860nm Wavelength Transmitter Sensor LS25CI.XR1/XX 50147917:
| Spec | Value |
|---|---|
| Operating Range | 0... 220 m |
| Dimension | 15 mm x 42.7 mm x 30 mm |
| Type of Connection | PUR Cable, 2m Length |
| Connection Function | Signal IN Voltage supply |
Leuze 860nm Wavelength Transmitter Sensor LS25CI.XR1/XX, 50147917 Technical Specifications:
| Specification | Value |
|---|---|
| Series | 25C |
| Operating principle | Throughbeam principle |
| Device type | Transmitter |
| Operating range | 0... 220 m |
| Light source | LED, Infrared |
| Wavelength | 860 nm |
| Power Supply | 10 ... 30 V, DC |
| Open-circuit current | 0 ... 20 mA |
| Readiness delay | 300 ms |
| Connection Function | Signal IN Voltage supply |
| Type of Connection | PUR Cable, 2m Length |
| Number of conductors or Pins | 4-wire |
| Dimension | 15 mm x 42.7 mm x 30 mm |
| Housing material | Plastic: ABS |
| Lens cover material | Plastic |
| Housing color | Red |
| Type of display | LED |
| Ambient temperature | Operation: -40 ... 60 °C Storage: -40 ... 70 °C |
| Degree of protection | IP 67, IP 69K |
| Net weight | 55 g |
Obtain a Quote for Leuze 860nm Wavelength Transmitter Sensor LS25CI.XR1/XX part no: 50147917 at attractive prices. Engineering Specifications of LS25CI.XR1/XX, 50147917 detail 25C series, Throughbeam, Transmitter device, 0... 220 m operating range, LED, Infrared light source, 860 nm wavelength, 10 ... 30 V, DC power supply, 0 ... 20 mA current, PUR Cable, 2m Length, 4-wire, 15 mm x 42.7 mm x 30 mm dimensions, Red housing color, LED display, IP 67, IP 69K degree of protection. Navigate Your Needs with a Quote for your requirement of Leuze 860nm Wavelength Transmitter Sensor. We excel in offering more cost-effective and supportive solutions than other Competitors.
