LS5I/9D-P1: 50130543 - Leuze Small Light Spot Transmitter Sensor
Technical Specifications of Leuze Small Light Spot Transmitter Sensor LS5I/9D-P1 50130543:
| Spec | Value |
|---|---|
| Operating Range | 0 ... 3 m |
| Dimension | 14 mm x 32.5 mm x 20.2 mm |
| Type of Connection | PUR Cable, 2m Length |
| Connection Function | Signal IN Voltage supply |
Leuze Small Light Spot Transmitter Sensor LS5I/9D-P1, 50130543 Technical Specifications:
| Specification | Value |
|---|---|
| Series | 5 |
| Operating principle | Throughbeam principle |
| Device type | Transmitter |
| Operating range | 0 ... 3 m |
| Light source | LED, Infrared |
| Wavelength | 850 nm |
| Power Supply | 10 ... 30 V, DC |
| Open-circuit current | 0 ... 15 mA |
| Readiness delay | 300 ms |
| Connection Function | Signal IN Voltage supply |
| Type of Connection | PUR Cable, 2m Length |
| Number of conductors or Pins | 4-wire |
| Dimension | 14 mm x 32.5 mm x 20.2 mm |
| Housing material | Plastic: ABS |
| Lens cover material | Plastic |
| Housing color | Black, Red |
| Type of display | LED |
| Ambient temperature | Operation: -40 ... 60 °C Storage: -40 ... 70 °C |
| Degree of protection | IP 67 |
| Net weight | 70 g |
Mail Us for your needs in Leuze Small Light Spot Transmitter Sensor LS5I/9D-P1 part no: 50130543 with budget-friendly prices. The Main Technical Parameters of LS5I/9D-P1, 50130543 include 5 series, Throughbeam, Transmitter device, deactivation input small light spot (S) special version, 0 ... 3 m operating range, LED, Infrared light source, 850 nm wavelength, 10 ... 30 V, DC power supply, 0 ... 15 mA current, PUR Cable, 2m Length, 4-wire, 14 mm x 32.5 mm x 20.2 mm dimensions, Black, Red housing color, LED display, IP 67 degree of protection. Customize Your Experience with a Quote for your requirement of Leuze Small Light Spot Transmitter Sensor. Experience the difference with our competitive pricing and superior support over other Suppliers.
