LSS 96K-1213-24: 50080657 - Leuze PFBS Throughbeam Transmitter Sensor
Technical Specifications of Leuze LSS 96K-1213-24 50080657:
| Spec | Value |
|---|---|
| Power Supply | 10 ... 30 V, DC |
| Device Type | Transmitter |
| Operating Range | 0... 39 m |
| Type of Connection | Terminal |
Leuze PFBS Throughbeam Transmitter Sensor LSS 96K-1213-24, 50080657 Technical Specifications:
| Specification | Value |
|---|---|
| Series | 96 |
| Operating principle | Throughbeam principle |
| Device type | Transmitter |
| Operating range | 0... 39 m |
| Light source | LED, Red |
| Power Supply | 10 ... 30 V, DC |
| Open-circuit current | 0 ... 50 mA |
| Type of Connection | Terminal |
| Number of conductors or Pins | 3-pin |
| Dimension (W x H x L) | 30 mm x 90 mm x 70 mm |
| Housing material | Plastic: PC |
| Lens cover material | Plastic |
| Note | Housing part used contains perfluorobutanesulfonic acid (PFBS) |
| Type of display | LED |
| Ambient temperature, operation | -40 ... 55 °C |
| Degree of protection | IP 67 |
| Net weight | 380 g |
Mail Us for your needs in Leuze PFBS Throughbeam Transmitter Sensor LSS 96K-1213-24 part no: 50080657 with budget-friendly prices. The Main Technical Parameters of LSS 96K-1213-24, 50080657 include 96 series, Throughbeam, Transmitter device, 0... 39 m operating range, LED, Red light source, 10 ... 30 V, DC power supply, 0 ... 50 mA current, Terminal, 3-pin, 30 mm x 90 mm x 70 mm dimensions, LED display, IP 67 degree of protection. Customize Your Experience with a Quote for your requirement of Leuze PFBS Throughbeam Transmitter Sensor. Experience the difference with our competitive pricing and superior support over other Suppliers.
