Leuze MSI 410-03 | 50132985
Technical Specifications of Leuze MSI 410-03 50132985:
| Spec | Value |
|---|---|
| Dimension (W x H x L) | 45 mm x 107 mm x 121 mm |
| Number of safe I/Os | 20 IN, 4 OUT |
| Supply voltage UB | 24 V, DC, -30 ... 25 % |
| Power consumption, max. | 3.3 W |
Leuze USB Interface Safety Controller MSI 410-03, 50132985 Technical Specifications:
| Specification | Value |
|---|---|
| Dimension (W x H x L) | 45 mm x 107 mm x 121 mm |
| Application | Monitoring of safety functions |
| Number of safe I/Os | 20 IN, 4 OUT |
| Supply voltage UB | 24 V, DC, -30 ... 25 % |
| Power consumption, max. | 3.3 W |
| Number of outputs | 4 Piece(s) |
| Type of digital output | Transistor |
| Number of inputs | 20 Piece(s) |
| Interface Type | USB |
| Number of connections | 2 Piece(s) |
| Con:1 Function | Signal IN Signal OUT Voltage supply |
| Type of connection | Terminal |
| Type of terminal | Spring-cage terminal |
| No. of pins | 31 -pin |
| Con:2 Function | Configuration interface |
| Type of connection | USB |
| Housing color | Gray |
| Type of fastening | Snap-on mounting |
| Ambient temperature, operation | -25 ... 65 °C |
| Ambient temperature, storage | -25 ... 70 °C |
| Degree of protection | IP 20 |
Call Us for Leuze USB Interface Safety Controller MSI 410-03 50132985 at competitive Prices. The Main Technical Parameters of MSI 410-03 are 45 mm x 107 mm x 121 mm Dimensions, - Number of Safe I/Os, 24 V, DC, -30 ... 25 % Supply Voltage, 3.3 W Power Consumption, USB Interface Type, Terminal Connection Spring-cage terminal, 31 -pin, Snap-on mounting, Gray Housing color, IP 20 degree of protection. Customize Your Experience with a Quote for your requirement of Leuze USB Interface Safety Controller.
