Leuze MSI-SR-2H21-03 | 50133017
Technical Specifications of Leuze MSI-SR-2H21-03 50133017:
| Spec | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 96.5 mm x 114 mm |
| Restart | Through synchronous actuation |
| Type of Terminal | Screw terminal |
| No. of pins | 16 -pin |
Leuze Through synchronous Safety Relay MSI-SR-2H21-03, 50133017 Technical Specifications:
| Specification | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 96.5 mm x 114 mm |
| Functions | For stop category 0 Monitoring of the synchronous actuation Two-channel actuation (one normally open contact and one normally closed contact for each) |
| Restart | Through synchronous actuation |
| Type of Terminal | Screw terminal |
| No. of pins | 16 -pin |
| Connection 1 Function | Signal IN Signal OUT Voltage supply |
| Number of connections | 1 Piece(s) |
| Response Time | 40 ms |
| Evaluation of the inputs | - |
| Input current | 60 mA |
| Supply Voltage UB | 24 V, AC/DC, -15 ... 10 % |
| Power consumption, max | 1.9 W, For 24 V, plus output load |
| Switching Output 1 | - |
| Type of fastening | Snap-on mounting |
| Housing Material | - |
| Housing Color | Gray |
| Ambient Temperature, Operation | -25 ... 55 °C |
| Ambient Temperature, Storage | -- |
| Degree of protection | - |
Reach Us by Email for Leuze Through synchronous Safety Relay, MSI-SR-2H21-03, 50133017 at competitive rates. Technical Attributes of MSI-SR-2H21-03 are -, --, -25 ... 55 °C, Gray
, Snap-on mounting, -, 1.9 W, For 24 V, plus output load & 40 ms. And It Delivers 24 V, AC/DC, -15 ... 10 %, 60 mA & -. Unlock Exclusive Pricing with a Quote for your requirement of Leuze Through synchronous Safety Relay. Rest assured, our pricing and support outshine other Suppliers
