Leuze MSI-SR5B-01 | 547952
Technical Specifications of Leuze MSI-SR5B-01 547952:
| Spec | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 99 mm x 114.1 mm |
| Restart | Automatic Manual |
| Type of Terminal | Screw terminal |
| No. of pins | 16 -pin |
Leuze Manual Restart Safety Relay MSI-SR5B-01, 547952 Technical Specifications:
| Specification | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 99 mm x 114.1 mm |
| Functions | Automatic start/restart Contactor monitoring (EDM) Cross circuit monitoring Double sensor monitoring Start/restart interlock (RES), selectable |
| Restart | Automatic Manual |
| Type of Terminal | Screw terminal |
| No. of pins | 16 -pin |
| Connection 1 Function | Connection to device |
| Number of connections | 1 Piece(s) |
| Response Time | - |
| Evaluation of the inputs | - |
| Input current | 150 mA |
| Supply Voltage UB | 24 V, DC, -20 ... 20 % |
| Power consumption, max | 4.8 W, For 24 V, plus output load |
| Switching Output 1 | Relay, NO |
| Type of fastening | Snap-on mounting |
| Housing Material | Plastic |
| Housing Color | Gray |
| Ambient Temperature, Operation | 0 ... 55 °C |
| Ambient Temperature, Storage | -25 ... 70 °C |
| Degree of protection | IP 20 (terminals) IP 40 (housing) |
Give Us a Call for Leuze Manual Restart Safety Relay MSI-SR5B-01 547952 at the lowest pricing. In-depth Technical Analysis of MSI-SR5B-01 includes 22.5 mm x 111 mm x 114.1 mm, Start/restart interlock (RES), Spring-cage terminal, 16 -pin Relay-NO etc. Elevate Your Project with a Quote for your requirement of Leuze Manual Restart Safety Relay. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
