Leuze MSI-TR1B-01 | 547958
Technical Specifications of Leuze MSI-TR1B-01 547958:
| Spec | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 99 mm x 114.1 mm |
| Restart | Automatic Manual |
| Type of Terminal | Screw terminal |
| No. of pins | 16 -pin |
Leuze Automatic Restart Safety Relay MSI-TR1B-01, 547958 Technical Specifications:
| Specification | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 99 mm x 114.1 mm |
| Functions | Error" signal output "Safety ON" signal output Contactor monitoring (EDM), selectable Periodic function test Start/restart interlock (RES), selectable |
| Restart | Automatic Manual |
| Type of Terminal | Screw terminal |
| No. of pins | 16 -pin |
| Connection 1 Function | Connection to device Voltage supply |
| Number of connections | 1 Piece(s) |
| Response Time | 20 ms |
| Evaluation of the inputs | - |
| Input current | - |
| Supply Voltage UB | 24 V, DC, -20 ... 20 % |
| Power consumption, max | 4.8 W, For 24 V, plus output load |
| Switching Output 1 | Transistor, PNP |
| Type of fastening | Snap-on mounting |
| Housing Material | Plastic |
| Housing Color | Gray |
| Ambient Temperature, Operation | -30 ... 60 °C |
| Ambient Temperature, Storage | -40 ... 70 °C |
| Degree of protection | IP 40 |
Send Your Inquiry for Leuze Automatic Restart Safety Relay MSI-TR1B-01 547958 with cost-effective solutions. Essential Technical Specs of MSI-TR1B-01 cover 22.5 mm x 99 mm x 114.1 mm, error and safety signal outputs, selectable contactor monitoring, periodic function tests, and start/restart interlock options. It also delivers screw terminals and PNP transistor output, Operating in temperatures from -30 to 60°C, it provides robust protection with an IP 40 rating. Capture the Best Deal with a Quote for your requirement of Leuze Automatic Restart Safety Relay. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
