Leuze MSI-TR2B-02 | 547961
Technical Specifications of Leuze MSI-TR2B-02 547961:
| Spec | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 111 mm x 114.1 mm |
| Restart | Automatic Manual |
| Type of Terminal | Spring-cage terminal |
| No. of pins | 16 -pin |
Leuze Transistor PNP Switching Safety Relay MSI-TR2B-02, 547961 Technical Specifications:
| Specification | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 111 mm x 114.1 mm |
| Functions | "Error" signal output "Safety ON" signal output Contactor monitoring (EDM) Increased availability through additional filter time Periodic function test Start/restart interlock (RES) |
| Restart | Automatic Manual |
| Type of Terminal | Spring-cage terminal |
| No. of pins | 16 -pin |
| Connection 1 Function | Connection to device Voltage supply |
| Number of connections | 1 Piece(s) |
| Response Time | 20 ms |
| Evaluation of the inputs | - |
| Input current | - |
| Supply Voltage UB | 24 V, DC, -20 ... 20 % |
| Power consumption, max | 4.8 W, For 24 V, plus output load |
| Switching Output 1 | Transistor, PNP |
| Type of fastening | Snap-on mounting |
| Housing Material | Plastic |
| Housing Color | Gray |
| Ambient Temperature, Operation | -30 ... 60 °C |
| Ambient Temperature, Storage | -40 ... 70 °C |
| Degree of protection | IP 40 |
IndMALL Offers Leuze Transistor PNP Switching Safety Relay MSI-TR2B-02 547961 at economical Choices. Product Tech Specs of MSI-TR2B-02 include dimensions of 22.5 mm x 111 mm x 114.1 mm, with spring-cage terminals and a 16-pin connection to devices. And It Includes voltage supply of 24V DC, with a response time of 20ms, PNP transistor output, snap-on mounting. Now's the Time to Secure a Quote for your requirement of Leuze Transistor PNP Switching Safety Relay. Trust in our superior pricing and more dedicated support over other Distributors.
