Leuze ODT25B/L6X.32-2500-S12 | 50148589
Technical Specifications of Leuze ODT25B/L6X.32-2500-S12 50148589:
| Spec | Value |
|---|---|
| Design | Cubic |
| Operating Principle | Distance diffuse sensor with background suppression |
| Sensing Distance | 0.05 ... 2.5 m |
| Light Source | LED, Infrared |
Leuze Distance diffuse sensor with background suppression 50148589 - ODT25B/L6X.32-2500-S12 Technical Specifications:
| Specification | Value |
|---|---|
| Design | Cubic |
| Operating principle | Distance diffuse sensor with background suppression |
| Sensing Distance | 0.05 ... 2.5 m |
| Beam path | Focused |
| Light source | LED, Infrared |
| Wavelength | 850 nm |
| Supply voltage UB | 18 ... 30 V, DC, Incl. residual ripple |
| Switching Output | Transistor, Push-pull |
| Switching principle | O-Link / light switching (PNP)/dark switching (NPN) |
| Switching frequency | 2 ... 30 Hz, depending on diffuse reflectance |
| Response time | 70 ms, depending on diffuse reflectance |
| Function | Signal OUTVoltage supply |
| Type of connection | Connector |
| Thread size | M12 |
| Type | Male |
| Material | Plastic |
| No. of pins | 5 -pin |
| Dimension (W x H x L) | 15 mm x 38.9 mm x 28.7 mm |
| Housing material | Plastic |
| Plastic housing | PC-ABS |
| Lens cover material | Plastic / PMMA |
| Housing color | Red |
| Type of display | LED |
| Ambient temperature, operation | -30 ... 50 °C |
| Ambient temperature, storage | -40 ... 60 °C |
| Degree of protection | IP 66/IP 67 |
Call us for ODT25B/L6X.32-2500-S12 part no.50148589 with budget-friendly prices. Technical Attributes of ODT25B/L6X.32-2500-S12 are Cubic, Design Distance diffuse sensor with background suppression, 15 mm x 38.9 mm x 28.7 mm Dimension, LED, Infrared Light source, Transistor, Push-pull Switching Outputs 1, O-Link / light switching (PNP)/dark switching (NPN) Switching principle, 18 ... 30 V, DC, Incl. residual ripple Supply voltage UB, 0.05 ... 2.5 m Sensing Distance, Connector Type of connection, Plastic Housing material, IP 66/IP 67 degree of protection. Now's the Time to Secure a Quote for your requirement of Leuze Distance diffuse sensor with background suppression. Rest assured, our pricing and support outshine other Suppliers.
