Leuze PRK328.3/4P | 50122696
Technical Specifications of Leuze PRK328.3/4P 50122696:
| Spec | Value |
|---|---|
| Design | Cubic |
| Operating Principle | Reflection principle |
| Sensing Distance | 0.02 ... 4.5 m, With reflector TK(S) 100x100 |
| Light Source | LED, Red |
Leuze cylindrical design, Plastic Lens cover retro-reflective photoelectric sensor PRK328.3/4P - 50122696 Technical Specifications:
| Specification | Value |
|---|---|
| Design | Cubic |
| Operating principle | Reflection principle |
| Application | - |
| Special version | - |
| Sensing Distance | 0.02 ... 4.5 m, With reflector TK(S) 100x100 |
| Beam path | - |
| Light source | LED, Red |
| Wavelength | 620 nm |
| Type of light spot geometry | - |
| Supply voltage UB | 10 ... 30 V, DC, Incl. residual ripple |
| Switching Output 1 | Transistor, PNP |
| Switching principle | Light switching |
| Switching Output 2 | Transistor, PNP |
| Switching principle | Dark switching |
| Switching frequency | 500 Hz |
| Response time | 1 ms |
| Function | Signal OUT Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PUR |
| Cable color | Black |
| Number of conductors | 4 -wire |
| Wire cross section | 0.2 mm² |
| Dimension (W x H x L) | 18 mm x 46 mm |
| Housing material | Plastic Stainless steel |
| Lens cover material | Plastic |
| Housing color | Black Silver |
| Type of display | LED |
| Operational controls | Teach button |
| Ambient temperature, operation | -40 ... 60 °C |
| Ambient temperature, storage | -40 ... 70 °C |
| Degree of protection | IP 67 |
Send Your Inquiry for Leuze cylindrical design, Plastic Lens cover retro-reflective photoelectric sensor PRK328.3/4P part no: 50122696 at affordable rates. Core System Specifications of PRK328.3/4P, 50122696 are Cubic, Design Reflection principle, 18 mm x 46 mm Dimension, LED, Red Light source, Transistor, PNP Switching Outputs 1, Light switching Switching principle, 10 ... 30 V, DC, Incl. residual ripple Supply voltage UB, 0.02 ... 4.5 m, With reflector TK(S) 100x100 Sensing Distance, 4 -wire Number of conductors, Plastic
Stainless steel Housing material, IP 67 degree of protection. Now's the Time to Secure a Quote for your requirement of Leuze cylindrical design, Plastic Lens cover retro-reflective photoelectric sensor. Initiate Your Journey with a Quote for your requirement of Leuze cylindrical design, Plastic Lens cover retro-reflective photoelectric sensor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other Suppliers & Traders.
