Leuze PRK328.3/4P-M12 | 50122695
Technical Specifications of Leuze PRK328.3/4P-M12 50122695:
| Spec | Value |
|---|---|
| Design | Cubic |
| Operating Principle | Reflection principle |
| Sensing Distance | 0.02 ... 4.5 m, With reflector TK(S) 100x100 |
| Light Source | LED, Red |
Leuze PRK 328 Series polarized retro-reflective photoelectric sensor PRK328.3/4P-M12 - 50122695 Technical Specifications:
| Specification | Value |
|---|---|
| Design | Cubic |
| Operating principle | Reflection principle |
| Application | - |
| Special version | - |
| Sensing Distance | 0.02 ... 4.5 m, With reflector TK(S) 100x100 |
| Beam path | - |
| Light source | LED, Red |
| Wavelength | 620 nm |
| Type of light spot geometry | - |
| Supply voltage UB | 10 ... 30 V, DC, Incl. residual ripple |
| Switching Output 1 | Transistor, PNP |
| Switching principle | Light switching |
| Switching Output 2 | Transistor, PNP |
| Switching principle | Dark switching |
| Switching frequency | 500 Hz |
| Response time | 1 ms |
| Function | Signal OUT Voltage supply |
| Type of connection | Connector |
| Thread size | M12 |
| Type | Male |
| Material | Plastic |
| No. of pins | 4 -pin |
| Encoding | A-coded |
| Dimension (W x H x L) | 18 mm x 46 mm |
| Housing material | Plastic Stainless steel |
| Metal housing | ABS |
| Lens cover material | Plastic |
| Housing color | Black Silver |
| Type of display | LED |
| Operational controls | Teach button |
| Ambient temperature, operation | -40 ... 60 °C |
| Ambient temperature, storage | -40 ... 70 °C |
| Degree of protection | IP 67 |
Get A Quote for Leuze PRK 328 Series polarized retro-reflective photoelectric sensor PRK328.3/4P-M12 part no: 50122695 at the best price. Here are the brief Technical Specifications of PRK328.3/4P-M12, 50122695 are Cubic, Design Reflection principle, 18 mm x 46 mm Dimension, LED, Red Light source, Transistor, PNP Switching Outputs 1, Light switching Switching principle, 10 ... 30 V, DC, Incl. residual ripple Supply voltage UB, 0.02 ... 4.5 m, With reflector TK(S) 100x100 Sensing Distance, 4 -pin No. of pins, Plastic
Stainless steel Housing material, IP 67 degree of protection. It's Time to get a Quote for your requirement of Leuze PRK 328 Series polarized retro-reflective photoelectric sensor. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
