Leuze PRK412B/2X-M12 | 50140146
Technical Specifications of Leuze PRK412B/2X-M12 50140146:
Spec | Value |
---|---|
Design | Cylindrical |
Operating Principle | Reflection principle |
Sensing Distance | 0.02 ... 1.8 m, With reflector TK(S) 100x100 |
Light Source | LED, Red |
Leuze 20 ms Readiness delay retro-reflective photoelectric sensor PRK412B/2X-M12 - 50140146 Technical Specifications:
Specification | Value |
---|---|
Design | Cylindrical |
Operating principle | Reflection principle |
Application | - |
Special version | - |
Sensing Distance | 0.02 ... 1.8 m, With reflector TK(S) 100x100 |
Beam path | - |
Light source | LED, Red |
Wavelength | 660 nm |
Type of light spot geometry | - |
Supply voltage UB | 10 ... 36 V, DC, Incl. residual ripple |
Switching Output 1 | Transistor, NPN |
Switching principle | Light switching |
Switching Output 2 | - |
Switching principle | - |
Switching frequency | 1,000 Hz |
Response time | 0.5 ms |
Function | Signal OUT Voltage supply |
Type of connection | Connector |
Thread size | M12 |
Type | - |
Material | Metal |
No. of pins | 4 -pin |
Encoding | A-coded |
Dimension (W x H x L) | 12 mm x 60 mm |
Housing material | Metal |
Metal housing | Chromed brass |
Lens cover material | Glass |
Housing color | Silver |
Type of display | LED |
Operational controls | - |
Ambient temperature, operation | -25 ... 55 °C |
Ambient temperature, storage | - |
Degree of protection | IP 67 |
Ask for the Pricing of Leuze 20 ms Readiness delay retro-reflective photoelectric sensor PRK412B/2X-M12 part no: 50140146 at unbeatable prices. Detailed Specifications of PRK412B/2X-M12, 50140146 feature Cylindrical, Design Reflection principle, 12 mm x 60 mm Dimension, LED, Red Light source, Transistor, NPN Switching Outputs 1, Light switching Switching principle, 10 ... 36 V, DC, Incl. residual ripple Supply voltage UB, 0.02 ... 1.8 m, With reflector TK(S) 100x100 Sensing Distance, 4 -pin No. of pins, Metal Housing material, IP 67 degree of protection. Now's the Time to Secure a Quote for your requirement of Leuze 20 ms Readiness delay retro-reflective photoelectric sensor. We're committed to offering more favorable pricing and more responsive support than other Traders.
