CP2E-E40DR-A: Omron PLC 40 Digital Outputs
Technical specifications of Omron PLC 40 Digital Outputs CP2E-E40DR-A:
Spec | Value |
---|---|
Inputs | 24 points |
Outputs | 16 points |
Output type | Relay |
Program capacity | 4K steps (FB capacity: 4K steps) |
Supply voltage | 100 to 240 VAC 50/60 Hz |
Omron PLC 40 Digital Outputs CP2E-E40DR-A Technical Specifications:
Specification | Value |
---|---|
Number of points | CPU Units with 40 points |
Inputs | 24 points |
Outputs | 16 points |
Output type | Relay |
Program capacity | 4K steps (FB capacity: 4K steps) |
Data memory capacity | 4K words |
Current consumption 5 VDC | 0.13 A |
Current consumption 24 VDC | 0.09 A |
Dimensions (H × D × W) | 90mm *1 × 80mm *2 × 150mm |
Supply voltage | 100 to 240 VAC 50/60 Hz |
Operating voltage range | 85 to 264 VAC |
Power consumption | 50 VA/100 VAC max., 70 VA/240 VAC max. |
Inrush current | 120 VAC, 20 A for 8 ms max. for cold start at room temperature 240 VAC, 40 A for 8 ms max. for cold start at room temperature |
Insulation resistance | 20 MΩ min. (at 500 VDC) between the external AC, terminals and GR terminals |
Power interrupt time | 10 ms min |
Altitude | 2,000 m max |
Atmosphere | No corrosive gas |
Ambient humidity | 10% to 90% |
Ambient operating temperature | 20 to 60°C |
Ambient storage temperature | -20 to 75°C (excluding battery) |
Weight | 640g max. |
Mail Us for your needs in Omron PLC 40 Digital Outputs CP2E-E40DR-A with budget-friendly prices. The Main Technical Parameters of CP2E-E40DR-Ainclude CPU Units with 40 points, 24 points inputs and 16 points Relay outputs. It features a program capacity of 4K steps (FB capacity: 4K steps) and a data memory capacity of 4K words. The PLC operates at 100 to 240 VAC 50/60 Hz with an operating voltage range of 85 to 264 VAC and a power consumption of 50 VA/100 VAC max., 70 VA/240 VAC max.. Its current consumption is 0.13 A at 5 VDC and 0.09 A at 24 VDC. The dimensions are 90mm *1 × 80mm *2 × 150mm. It has an insulation resistance of 20 MΩ min. (at 500 VDC) between the external AC, terminals and GR terminals, and can handle power interruptions of 10 ms min. at altitudes up to 2,000 m max with No corrosive gas. Customize Your Experience with a Quote for your requirement of Omron PLC 40 Digital Outputs. Experience the difference with our competitive pricing and superior support over other Suppliers.
