E2B-S08KS02-MC-B1 : Omron M8 Proximity Sensor in Chennai
Technical specifications of Omron M8 Proximity Sensor E2B-S08KS02-MC-B1:
- The M8 Dia is specified.
- The sensing distance is 2mm.
- The installation type is flush.
- The output is PNP.
- The switching function is Normally Open (NO).
- The sensor length is 44mm.
- The operating voltage range is from 10 to 30 VDC.
- The electrical connection is made via an M8 Connector (3-pin)
Omron M8 Proximity Sensor E2B-S08KS02-MC-B1 Technical Specifications:
| Sensor Head (Dia) | M8 |
| Installation | Flush | Shield |
| Sensing Distance | 2 mm |
| Body Length | Short (44mm) |
| Output Configuration | PNP |
| Switching | NO (Normally Open) |
| Connection | M8 Connector (3-pin) |
| Differential travel | 10% max. of sensing distance |
| Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard sensing object | 8 × 8 × 1 mm |
| Response frequency | 1,500 Hz |
| Power supply voltage | 10 to 30 VDC. (including 10% ripple (p-p)) |
| Current consumption | 10 mA max |
| Indicator | Operation indicator (Yellow LED) |
| Protection circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Short-circuit protection |
| Ambient air temperature | Operation and storage: -25 to 70ºC |
| Ambient humidity | Operation and Storage: 35 to 95% |
| Voltage influence | ±1% max. of sensing distance in 24 V ±15% |
| Standard and listings | (1) IP67 (IEC60529) (2) EMC (EN60947-5-2) |
| Material Case | Stainless steel (1.4305 (W.-No.), SUS 303 (AISI), 2346 (SS).) |
| Material Sensing surface | PBT |
| Material Cable | None |
| Material Clamping nut | Brass-nickel plated |
The Omron M8 Proximity Sensor featured in IndMALL a Chennai based company, product range as Omron E2B-S08KS02-MC-B1 stands out with its compact M8 sensor head and a short body length of 44mm, ensuring seamless integration in tight spaces. This sensor offers reliable detection with a 2mm sensing distance and operates with a PNP output configuration. Its design allows for flush or shielded installation, making it versatile for various applications. It also features a normally open (NO) switching mechanism and a maximum differential travel of 10% of the sensing distance.
