Omron E2E-X10E1-M1: Proximity Sensor 24VDC in Chennai
The technical specifications for the Omron E2E-X10E1-M1 Proximity Sensor 24VDC are:
- Sensor Head (Dia): M30
- Installation: Flush | Shielded
- Sensing Distance: 10 mm
- Connection Method: M12 Connector
- Switching: NO
- Output Configuration: NPN, DC 3 Wire
- Response Frequency: 0.4 KHz
- Power Supply Voltage: 12 to 24 VDC
Omron E2E-X10E1-M1 Proximity Sensor 24VDC Technical Specification:
| Sensor Head (Dia) | M30 |
| Installation | Flush | Shielded |
| Sensing Distance | 10 mm |
| Connection Method | M12 Connector Models |
| Switching | NO |
| Output Configuration | NPN, DC 3 Wire |
| Differential travel | 10% max. of sensing distance |
| Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard sensing object | Iron, 30 × 30 × 1 mm |
| Response frequency | 0.4 KHz |
| Power supply voltage | 12 to 24 VDC ripple (p-p) 10% max. |
| Leakage current | 13 mA max |
| Indicator | Operation indicator (red) |
| Protection circuit | Load short-circuit protection, Surge suppressor, Reverse polarity protection |
| Ambient air temperature | Operating Storage: −40 to 85°C (with no icing or condensation) |
| Ambient humidity | Operating/storage: 35% to 95% (with no condensation) |
| Voltage influence | ±1% max. of sensing distance at the rated voltage in the rated voltage ±15% range |
| Degree of protection | IEC 60529 IP67, in-house standards: oil-resistant |
| Material Case | Stainless steel (SUS303) |
| Material Sensing surface | PBT |
Are you looking for the Omron E2E-X10E1-M1 proximity sensor 24VDC in Chennai? You’ve arrived at the right spot. The Omron Inductive Sensor features an M30 diameter, a sensing distance of 10 mm, a Normally Open (NO) switch, a power supply range of 12 to 24 VDC, an NPN output, and an M12 Connector Model. Trust IndMALL Automation for competitive rates on this high-quality sensor.
