E3RB-DP12 2M: Omron PNP Diffuse Sensor with Easy Setup
Technical Specifications of E3RB-DP12 2M Omron PNP Diffuse Sensor with Easy Setup
| Spec | Value |
|---|---|
| Shape | Cylindrical radial |
| Sensing Method | Diffuse-reflective |
| Sensing Distance | 300mm |
Omron PNP Diffuse Sensor with Easy Setup E3RB-DP12 2M Technical Specifications:
| Specification | Value |
|---|---|
| Shape | Cylindrical radial |
| Sensing Method | Diffuse-reflective |
| Sensing Distance | 300mm |
| Light Source Wavelength | Red LED |
| Connection Method | Pre Wired Cable,2M Length |
| Power Supply Voltage | 10 to 30 VDC |
| Output Configuration | PNP |
| Power Consumption | 25 mA max. |
| Operation Mode | Light-ON/Dark-ON |
| Thread Size | M18 |
| Length | 57mm |
| Response Time | 0.5ms |
| Degree of Protection | IP67/IP69K |
| Material Housing | Brass, nickel plated |
| Features | NA |
Mail Us for your needs in Omron PNP Diffuse Sensor with Easy Setup E3RB-DP12 2M with budget-friendly prices. The Main Technical Parameters of E3RB-DP12 2M include Cylindrical radial in shape, M18 thread size, Diffuse reflective, 300mm sensing distance, Red LED, Pre-wired cable of 2M length, PNP configuration , 25mA max power consumption, 57 mm length, 0.5ms response time. Customize Your Experience with a Quote for your requirement of Omron PNP Diffuse Sensor with Easy Setup. Experience the difference with our competitive pricing and superior support over other Suppliers.
