E5CD-QX2A6M-000: Omron Digital PID Controller in Chennai
The Omron Digital PID Controller E5CD-QX2A6M-000 Technical Specifications are:
- Size: DIN48 x 48
- Control Method: ON/OFF or 2-PID control
- Number of input points: 1 point
- Control output 1: Voltage output (for driving SSR)
- Control output 2: None
- Indication method: 11-segment digital display
- Setting Method: Digital setting using front panel keys
- Power supply voltage:100 to 240 VAC
Omron Digital PID Controller E5CD-QX2A6M-000 Technical Specifications:
| Size | DIN48 x 48 |
| Control Method | ON/OFF control or 2-PID control (with auto-tuning) |
| Number of input points | 1 point |
| Temperature input type | Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, PLII Platinum resistance thermometer: Pt100, JPt100 Infrared Thermosensor: 10 to 70 ℃, 60 to 120 ℃, 115 to 165 ℃, 140 to 260 ℃ |
| Analog input type | Current input: 4 to 20 mA or 0 to 20 mA Voltage input: 1 to 5 V, 0 to 5 V, 0 to 10 V, 0 to 50 mV |
| Number of total control output | 1 point |
| Control output 1 | Voltage output (for driving SSR) |
| Control output 2 | None |
| Indication method | 11-segment digital display and individual indicators |
| Setting Method | Digital setting using front panel keys |
| Power supply voltage | 100 to 240 VAC |
| Ambient operating temperature | −10 to 55°C (with no condensation or icing), For 3-year warranty: −10 to 50°C with standard mounting (with no condensation or icing) |
| Ambient operating humidity | 25% to 85% |
| Storage temperature | −25 to 65°C (with no condensation or icing) |
| Allowable voltage variable range | 85 to 110% of the power supply voltage |
| Power consumption | 5.2 VA max. (at 100 to 240 VAC) |
| Terminal | Screw terminal blocks |
Looking for a reliable Omron Digital PID Controller E5CD-QX2A6M-000 is a great choice. This compact DIN48 x 48 controller offers ON/OFF or 2-PID control methods and has one input point. It features a voltage output for driving SSRs, an 11-segment digital display, and easy digital settings via front panel keys. Operating on 100 to 240 VAC, it’s perfect for various applications. Get the best deals on Omron controllers at IndMALL Automation in Chennai.
