E5CD-QX2D6M-000 - Omron Digital Temperature Controller
E5CD-QX2D6M-000 is an advanced Omron Digital Temperature Controller built for precise and compact industrial temperature control.
| Spec | Value |
|---|---|
| Brand | Omron |
| Product Type | Temperature Controller |
| Product | E5CD-QX2D6M-000 |
Omron Digital Temperature Controller E5CD-QX2D6M-000 Technical Specifications
| Specification | Value |
|---|---|
| Shape | 48 × 48 mm |
| Power supply voltage | 24 VAC, 50/60 Hz; 24 VDC |
| Operating voltage range | 85% to 110% of rated supply voltage |
| Power consumption | 5.2 VA max. at 100 to 240 VAC, and 3.1 VA max. at 24 VAC or 1.6 W max. at 24 VDC |
| Control method | ON/OFF or 2-PID control with auto-tuning |
| Number of input points | 1 point |
| Input Type/Temperature input | Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, PLII Platinum resistance thermometer: Pt100, JPt100 Infrared Thermosensor: 10 to 70 ℃, 60 to 120 ℃, 115 to 165 ℃, 140 to 260 ℃ |
| Control output 1 | Voltage output |
| Control output 2 | None |
| Number of total auxiliary output | 2 |
| Setting method | Digital setting using front panel keys |
| Indication method | 11-segment digital display, individual indicators, and bar display |
| Insulation resistance | 20 MΩ min. (at 500 VDC) |
| Dielectric strength | 3,000 VAC, 50/60 Hz for 1 min between terminals of different charge |
| Vibration resistance | 10 to 55 Hz, 20 m/s2 for 2 hrs each in X, Y, and Z directions |
| Shock resistance | 300 m/s2, 3 times each in X, Y, and Z directions |
| Ambient temperature (Operating) | -10 to 55 ℃ (with no freezing or condensation) For 3-year warranty with standard mounting: -10 to 50 ℃ (with no freezing or condensation) |
| Ambient temperature (Storage) | −25 to 65°C (with no condensation or icing) |
| Ambient humidity (Operating) | 25% to 85% |
| Degree of protection | IP66, Rear case: IP20, Terminals: IP00 |
| Terminal type | Screw terminal blocks |
| Weight | Controller: Approx. 210 g, Adapter: Approx. 4 g × 2 |
🛠️ Get Quotes Instantly from Omron Vendors
Techtonic Automation & Vision System
✔ Verified
Deals in PAN India
Omron is a leading global brand in the field of industrial automation and control. Known for its innovation, precision, and durability, Omron’s products are trusted by engineers and industries across the world. Whether it's temperature control, sensing, or machine safety, Omron delivers solutions that enhance efficiency and reliability on factory floors, in laboratories, and in OEM applications. Its products are designed to meet the evolving needs of automation, ensuring smooth operations in even the most demanding environments.
The Omron E5CD-QX2D6M-000 is a compact, high-performance digital temperature controller sized at 48 × 48 mm. It supports 24 VAC or 24 VDC input power, making it suitable for low-voltage environments. This model is equipped with a voltage output for controlling SSRs and offers ON/OFF as well as advanced 2-PID control with auto-tuning. It accepts a wide range of input types—thermocouples, RTDs like Pt100, JPt100, and even infrared sensors—giving it exceptional flexibility. The unit features a clear 11-segment digital display with bar indicators, allowing users to monitor temperature status easily. It includes two auxiliary outputs and is designed with high resistance to shock, vibration, and electrical noise. Its IP66-rated front panel provides excellent protection in dusty or humid conditions, making it highly dependable in real-world industrial settings.
Applications of the E5CD-QX2D6M-000 are widespread across temperature-sensitive operations. In plastic molding units, it ensures consistent mold temperatures, which directly impacts product quality and cycle time. In ovens, dryers, and food processing machines, it maintains precise heating conditions, helping reduce waste and improve batch consistency. In HVAC systems, this controller helps balance energy use and comfort levels. It's also ideal for pharmaceutical, textile, and lab-based applications where even slight temperature changes can affect outcomes. Maintenance engineers appreciate its straightforward digital setup and wide sensor compatibility, which make it easy to integrate and configure. The low-voltage input feature is particularly helpful in control panels that are powered by 24 VDC supplies, making it both safe and adaptable for a variety of machine environments.
