E6C2-CWZ6C 720P/R 2M: Omron 720 PPR Reliable Encoder
Technical Specifications of Omron 720 PPR Reliable Encoder E6C2-CWZ6C 720P/R 2M:
| Spec | Value |
|---|---|
| Encoding Method | Incremental Shaft model |
| Resolution | 720 P/R |
| Output phases | A, B and Z |
| Control output | NPN voltage output |
| Connection method | Pre-wired models (Cable length: 2 m) |
Omron 720 PPR Reliable Encoder E6C2-CWZ6C 720P/R 2M Technical Specifications:
| Specification | Value |
|---|---|
| Encoding Method | Incremental Shaft model |
| Resolution | 720 P/R |
| Output phases | A, B and Z |
| Control output | NPN voltage output |
| Connection method | Pre-wired models (Cable length: 2 m) |
| Diameter | 50 mm dia. |
| Power supply voltage | 5 to 24 VDC (-5% to +15%) Ripple (p-p) 5% max. |
| Current consumption | 80 mA max. |
| Inrush current | Approx. 9 A (0.3 ms) |
| Max. response frequency | 100 kHz |
| Ambient temperature | Operating: -10 to 70 ℃ (with no icing) Storage: -25 to 85 ℃ (with no icing) |
| Degree of protection | IEC: IP64 |
| Material | Case: Zinc alloy |
| Weight | Package: Approx. 400 g |
| Accessories | Instruction manual |
The Omron E6C2-CWZ6C 720P/R 2M is a reliable and precise incremental rotary encoder designed for industrial motion control. It has a resolution of 720 pulses per revolution (PPR), making it ideal for accurate position and speed measurement. This encoder features a 2-meter pre-wired cable for easy installation, an NPN voltage output, and operates with a maximum current of 80 mA. It offers a fast response frequency of 100 kHz, ensuring smooth and efficient operation.
If you need an Omron 720 PPR Reliable Encoder, the E6C2-CWZ6C 720P/R 2M is a great choice for industrial automation systems. With its compact and efficient design, it meets various requirements while delivering high performance. IndMALL Automation offers competitive pricing and dependable support for all your 720 PPR rotary encoder needs.
