G2R-2-SNDI DC24 (S): Omron Double Pole Relay in Chennai
The technical specifications for the Omron Double Pole Relay G2R-2-SNDI DC24 (S) are:
- Terminal Structure: Plug-in terminal
- Coil ratings: 24 VDC 25.6 mA
- Operating indicator: LED/Mechanical indicator
- Contact form: SPDT
- Mounting method: Socket
- Degree of protection: Closed type (cover)
- Contact Resistance:100 mΩ max
Omron Double Pole Relay G2R-2-SNDI DC24 (S) Technical Specifications:
| Degree of protection | Closed type (cover) |
| Terminal structure | Plug-in terminal |
| Coil ratings | 24 VDC 25.6 mA |
| Operating indicator | LED/Mechanical indicator |
| Coil resistance | 1113 Ω |
| Operate voltage (Set voltage) | 70% max. |
| Release voltage (Reset voltage) | 15% min. |
| Power consumption | Approx. 0.53 W |
| Maximum voltage | 110% |
| Contact rated load | 250 VAC 5 A (Resistive load) 250 VAC 2 A (Inductive load (cosφ = 0.4)) 30 VDC 5 A (Resistive load) 30 VDC 3 A (Inductive load (L/R = 7 ms)) |
| Max. contact voltage | 440 VAC 125 VDC |
| Max. contact current | AC: 10 A DC: 10 A |
| Maximum switching power | 1250 VA (Resistive load) 500 VA (Inductive load (cosφ = 0.4)) 150 W (Resistive load) 90 W (Inductive load (L/R = 7 ms)) |
| Contact form | DPDT |
| Contact resistance | 100 mΩ max. (Voltage drop method with 5 VDC 1 A) |
| Operating time | 15 ms max. (With rated operating power applied, not including contact bounce) |
| Reset time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Maximum operating frequency | Mechanical: 18000 time/h Rated load: 1800 time/h |
| Ambient temperature (Operating) | -40 to 70℃ (with no freezing or condensation) |
| Ambient humidity (Operating) | 5 to 85% |
| Mounting method | Socket |
Are you looking for an efficient Omron Double Pole Relay in Chennai? IndMALL Automation offers the G2R-2-SNDI DC24 (S) at competitive prices. This relay features a closed cover, plug-in terminals, and an LED/mechanical indicator. It operates on a 24 VDC coil, with a power consumption of about 0.53 W. Capable of handling up to 5 A for AC and 3 A for DC, it’s designed to work well in temperatures from -40 to 70℃, making it suitable for various applications.
