MY2N-D2 DC100/110: Omron MY2N Relay Socket in Chennai
The technical specifications for the Omron MY2N Relay Socket MY2N-D2 DC100/110:
- Degree of protection: Closed type (cover)
- Terminal structure: Plug-in terminal
- Contact form: DPDT
- Mounting method: Socket
- Power consumption: Approx. 0.9 W
- Operating indicator: 100 VDC 8.7 mA / 9.6 mA
- Contact method: Single
Omron MY2N Relay Socket MY2N-D2 DC100/110 Technical Specifications:
| Degree of protection | Closed type (cover) |
| Terminal structure | Plug-in terminal |
| Coil ratings | 100 VDC 8.7 mA 110 VDC 9.6 mA |
| Coil resistance | 11440 Ω |
| Operate voltage (Set voltage) | 80% max. |
| Release voltage (Reset voltage) | 10 % min. |
| Power consumption | Approx. 0.9 W |
| Contact rated load | 220 VAC 5 A (Resistive load) 220 VAC 2 A (Inductive load (cosφ = 0.4)) 24 VDC 5 A (Resistive load) 24 VDC 2 A (Inductive load (L/R = 7 ms)) |
| Max. contact voltage | 250 VAC 125 VDC |
| Max. Contact Current | AC: 5 A DC: 5 A |
| Maximum switching power | 1100 VA (Resistive load) 440 VA (Inductive load (cosφ = 0.4)) 120 W (Resistive load) 48 W (Inductive load (L/R = 7 ms)) |
| Contact method | Single |
| Contact form | DPDT |
| Contact resistance | 50 mΩ max. (Voltage drop method with 5 VDC 1 A) |
| Contact material | Ag |
| Operating time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Reset time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Maximum operating frequency | Mechanical: 18000 time/hour Rated load: 1800 time/hour |
| Ambient temperature (Operating) | -55 to 60 ℃ (with no freezing or condensation) |
| Ambient humidity (Operating) | 5 to 85% |
| Mounting method | Socket |
Are you searching for a reliable relay in Chennai? The Omron MY2N Relay Socket MY2N-D2 DC100/110 is a great find. It’s designed with a secure cover and easy plug-in terminals. This relay operates efficiently with low power consumption and has a high coil resistance. It’s perfect for handling both AC and DC loads up to 5 A, ensuring stable performance in various conditions. Get the best prices for this relay at IndMALL Automation.
