MY4 AC200/220: Omron 4 Pole Relay in Chennai
The technical specifications for the Omron 4 Pole Relay MY4 AC200/220:
- Contact form: 4PDT
- Contact method: Single
- Contact material: Au clad + Ag alloy
- Degree of protection: Closed type (cover)
- Terminal structure: Plug-in terminal
- Coil resistance: 12950 Ω
- Power consumption: Approx. 0.9 to 1.3 VA 60 Hz
- Mounting method: Socket
Omron 4 Pole Relay MY4 AC200/220 Technical Specifications:
| Degree of protection | Closed type (cover) |
| Terminal structure | Plug-in terminal |
| Coil ratings | 200 VAC 50 Hz 6.2 mA 200 VAC 60 Hz 5.3 mA 220 VAC 50 Hz 6.8 mA 220 VAC 60 Hz 5.8 mA |
| Coil resistance | 12950 Ω |
| Operate voltage (Set voltage) | 80% max. |
| Release voltage (Reset voltage) | 10 % min. |
| Power consumption | Approx. 0.9 to 1.3 VA 60 Hz |
| Contact rated load | 220 VAC 3 A (Resistive load) 220 VAC 0.8 A (Inductive load (cosφ = 0.4)) 24 VDC 3 A (Resistive load) 24 VDC 1.5 A (Inductive load (L/R = 7 ms)) |
| Max. contact voltage | 250 VAC 125 VDC |
| Max. Contact Current | AC: 3 A DC: 3 A |
| Maximum switching power | 660 VA (Resistive load) 176 VA (Inductive load (cosφ = 0.4)) 72 W (Resistive load) 36 W (Inductive load (L/R = 7 ms)) |
| Contact method | Single |
| Contact form | 4PDT |
| Contact resistance | 50 mΩ max. (Voltage drop method with 5 VDC 1 A) |
| Contact material | Au clad + Ag alloy |
| Operating time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Reset time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Maximum operating frequency | Mechanical: 18000 time/hour Rated load: 1800 time/hour |
| Ambient temperature (Operating) | -55 to 70 ℃ (with no freezing or condensation) |
| Ambient humidity (Operating) | 5 to 85% |
| Mounting method | Socket |
| Weight | Approx. 35 g |
Are you looking for the Omron 4 Pole Relay MY4 AC200/220. It features a 4PDT contact form with a single contact method, Au clad + Ag alloy contact material. This closed-type relay has plug-in terminals, a coil resistance of 12950 Ω, and consumes about 0.9 to 1.3 VA at 60 Hz. It’s designed for socket mounting. IndMALL Automation in Chennai is the place to check for competitive Omron Relay prices.
