MY4H DC24: Omron MY4H Relay in Chennai
The technical specifications for the Omron MY4H Relay MY4H DC24:
- Terminal structure: Plug-in terminal
- Coil ratings: 24 VDC 36.9 mA
- Coil resistance: 650 Ω
- Contact form: 4PDT
- Contact method: Single
- Degree of protection: Hermetically sealed
- Mounting method: Socket
- Power consumption: Approx. 0.9 W
- Ambient temperature: -25 to 60 ℃
Omron MY4H Relay MY4H DC24 Technical Specifications:
| Degree of protection | Hermetically sealed |
| Terminal structure | Plug-in terminal |
| Coil ratings | 24 VDC 36.9 mA |
| Coil resistance | 650 Ω |
| Operate voltage (Set voltage) | 80% max. |
| Release voltage (Reset voltage) | 10 % min. |
| Coil Maximum voltage | 110 % (23 ℃) |
| Power consumption | Approx. 0.9 W |
| Contact rated load | 110 VAC 3 A (Resistive load) 110 VAC 0.8 A (Inductive load (cosφ = 0.4)) 24 VDC 3 A (Resistive load) 24 VDC 1.5 A (Inductive load (L/R = 7 ms)) |
| Max. contact voltage | 125 VAC 125 VDC |
| Max. Contact Current | AC: 3 A DC: 3 A |
| Maximum switching power | 330 VA (Resistive load) 88 VA (Inductive load (cosφ = 0.4)) 72 W (Resistive load) 36 W (Inductive load (L/R = 7 ms)) |
| Contact method | Single |
| Contact form | 4PDT |
| Contact resistance | 50 mΩ max. (Voltage drop method with 5 VDC 1 A) |
| Contact material | Au plating + Ag |
| Operating time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Reset time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Maximum operating frequency | Mechanical: 18000 time/hour Rated load: 1800 time/hour |
| Ambient temperature (Operating) | -25 to 60 ℃ (with no freezing or condensation) |
| Ambient humidity (Operating) | 5 to 85% |
| Mounting method | Socket |
| Weight | Approx. 35 g |
Are you looking for the Omron MY4H Relay MY4H DC24 is an excellent choice. It features plug-in terminals and operates on 24 VDC with a coil rating of 36.9 mA and a resistance of 650 Ω. This 4PDT relay with single contact method is designed for socket mounting and consumes about 0.9 W. It’s suitable for ambient temperatures from -25 to 60 ℃. For the best Omron Relay prices, IndMALL Automation in Chennai is the place to check.
