MY4Z DC100/110: Omron Relay MY4Z 110VDC in Chennai
The technical specifications for the MY4Z DC100/110 Omron Relay MY4Z 110VDC:
- Degree of protection: Closed type (cover)
- Terminal structure: Plug-in terminal
- Coil ratings: 100 VDC 8.7 mA/110 VDC 9.6 mA
- Coil resistance: 11440 Ω
- Contact form: 4PDT
- Contact method: Bifurcated
- Power consumption: Approx. 0.9 W
- Ambient temperature: -55 to 70 ℃
- Mounting method: Socket
MY4Z DC100/110 Omron Relay MY4Z 110VDC Technical Specifications:
| Degree of protection | Closed type (cover) |
| Terminal structure | Plug-in terminal |
| Coil ratings | 100 VDC 8.7 mA 110 VDC 9.6 mA |
| Coil resistance | 11440 Ω |
| Operate voltage (Set voltage) | 80% max. |
| Release voltage (Reset voltage) | 10 % min. |
| Coil Maximum voltage | 110 % (23 ℃) |
| Power consumption | Approx. 0.9 to 1.3 VA 60 Hz |
| Contact rated load | 220 VAC 3 A (Resistive load) 220 VAC 0.8 A (Inductive load (cosφ = 0.4)) 24 VDC 3 A (Resistive load) 24 VDC 1.5 A (Inductive load (L/R = 7 ms)) |
| Max. contact voltage | 250 VAC 125 VDC |
| Max. Contact Current | AC: 3 A DC: 3 A |
| Maximum switching power | 660 VA (Resistive load) 176 VA (Inductive load (cosφ = 0.4)) 72 W (Resistive load) 36 W (Inductive load (L/R = 7 ms)) |
| Contact method | Bifurcated |
| Contact form | 4PDT |
| Contact resistance | 50 mΩ max. (Voltage drop method with 5 VDC 1 A) |
| Contact material | Au clad + Ag alloy |
| Operating time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Reset time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Maximum operating frequency | Mechanical: 18000 time/hour Rated load: 1800 time/hour |
| Ambient temperature (Operating) | -55 to 70 ℃ (with no freezing or condensation) |
| Ambient humidity (Operating) | 5 to 85% |
| Mounting method | Socket |
| Weight | Approx. 35 g |
Are you looking for the Omron Relay MY4Z 110VDC? This MY4Z DC100/110 relay features a bifurcated contact method, is mounted using a socket, has a closed protective cover, and has plug-in terminals. The coil operates at 100 VDC (8.7 mA) or 110 VDC (9.6 mA) with a resistance of 11,440 ohms. It’s a 4PDT type, consumes about 0.9 W, and works well in temperatures from -55 to 70℃. For competitive prices on Omron Relays, visit IndMALL Automation in Chennai.
