NJ101-9020: Omron PLC 3MB Program Capacity
Technical specifications of Omron PLC 3MB Program Capacity NJ101-9020:
| Spec | Value |
|---|---|
| Controller functionality | DB connection, Sequence control |
| Program memory | 3 MB |
| Communication port(s) | EtherCAT Master, EtherNet/IP, USB |
| Max. number of remote I/O nodes | 64 |
Omron PLC 3MB Program Capacity NJ101-9020 Technical Specifications:
| Specification | Value |
|---|---|
| Controller functionality | DB connection, Sequence control |
| Max. number of PTP axes | - |
| Primary task cycle time | 1 ms |
| Program memory | 3 MB |
| Variables memory | 0.5 MB |
| Communication port(s) | EtherCAT Master, EtherNet/IP, USB |
| Communication option(s) | CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485 |
| Max. number of remote I/O nodes | 64 |
| I/O system | CJ I/O Bus |
| Max. number of expansion units | 40 |
| Product Height (unpacked) | 97.5 mm |
| Product Width (unpacked) | 90 mm |
| Product Depth (unpacked) | 90 mm |
| Product Weight (unpacked) | 550 g |
Give Us a Call for Omron PLC 3MB Program Capacity NJ101-9020 at the lowest pricing. In-depth Technical Analysis of NJ101-9020 feature advanced controller functionality, including DB connection, Sequence control. The primary task cycle time is 1 ms, with a program memory of 3 MB and variables memory of 0.5 MB. Communication ports include EtherCAT Master, EtherNet/IP, USB, along with options for CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485. The PLC can handle a maximum of 64 remote I/O nodes and 40 expansion units via the CJ I/O Bus. The product dimensions are 97.5 mm in height, 90 mm in width, and 90 mm in depth. Elevate Your Project with a Quote for your requirement of Omron PLC 3MB Program Capacity. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
