NJ501-1320: Omron PLC Sysmac NJ5 CPU
Technical specifications of Omron PLC Sysmac NJ5 CPU NJ501-1320:
| Spec | Value |
|---|---|
| Controller functionality | DB connection, Motion control, Sequence control |
| Max. number of synchronous axes | 16 |
| Program memory | 20 MB |
| Communication port(s) | EtherCAT Master, EtherNet/IP, USB |
| Max. number of remote I/O nodes | 192 |
Omron PLC Sysmac NJ5 CPU NJ501-1320 Technical Specifications:
| Specification | Value |
|---|---|
| Controller functionality | DB connection, Motion control, Sequence control |
| Max. number of synchronous axes | 16 |
| Max. number of PTP axes | 16 |
| Max. number of axes (incl. virtual) | - |
| Primary task cycle time | 0.5 ms |
| Program memory | 20 MB |
| Variables memory | 6 MB |
| Communication port(s) | EtherCAT Master, EtherNet/IP, USB |
| Communication option(s) | CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485 |
| Max. number of remote I/O nodes | 192 |
| I/O system | CJ I/O Bus |
| Max. number of expansion units | 40 |
| Product Height (unpacked) | 96 mm |
| Product Width (unpacked) | 90 mm |
| Product Depth (unpacked) | 150 mm |
| Product Weight (unpacked) | 550 g |
Talk to Our Engineer for Omron PLC Sysmac NJ5 CPU NJ501-1320 with exclusive offers. Core System Specifications of NJ501-1320 are advanced controller functionality, including DB connection, Motion control, Sequence control. It supports up to 16 synchronous axes, 16 PTP axes, including virtual ones. The primary task cycle time is 0.5 ms, with a program memory of 20 MB and variables memory of 6 MB. Communication ports include EtherCAT Master, EtherNet/IP, USB, along with options for CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485. The PLC can handle a maximum of 192 remote I/O nodes and 40 expansion units via the CJ I/O Bus. The product dimensions are 96 mm in height, 90 mm in width, and 150 mm in depth. Don't Miss Out on a Quote for your requirement of Omron PLC Sysmac NJ5 CPU. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
