NJ501-R500: Omron PLC 20MB Program Capacity
Technical specifications of Omron PLC 20MB Program Capacity NJ501-R500:
| Spec | Value |
|---|---|
| Controller functionality | Motion control, Robotics, Sequence control |
| Max. number of synchronous axes | 64 |
| Program memory | 20 MB |
| Communication port(s) | EtherCAT Master, EtherNet/IP, USB |
| Max. number of remote I/O nodes | 192 |
Omron PLC 20MB Program Capacity NJ501-R500 Technical Specifications:
| Specification | Value |
|---|---|
| Controller functionality | Motion control, Robotics, Sequence control |
| Max. number of synchronous axes | 64 |
| Max. number of PTP axes | - |
| Max. number of axes (incl. virtual) | 64 |
| Primary task cycle time | 0.5 ms |
| Program memory | 20 MB |
| Variables memory | 6 MB |
| Communication port(s) | EtherCAT Master, EtherNet/IP, USB |
| Communication option(s) | CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485 |
| Max. number of remote I/O nodes | 192 |
| I/O system | CJ I/O Bus |
| Max. number of expansion units | 40 |
| Product Height (unpacked) | - |
| Product Width (unpacked) | - |
| Product Depth (unpacked) | - |
| Product Weight (unpacked) | 675.494 g |
Obtain a Quote for Omron PLC 20MB Program Capacity NJ501-R500 at economical prices. Specifications Overview for NJ501-R500 reveals advanced controller functionality, including Motion control, Robotics, Sequence control. It supports up to 64 synchronous axes, and 64 total axes, including virtual ones. The primary task cycle time is 0.5 ms, with a program memory of 20 MB and variables memory of 6 MB. Communication ports include EtherCAT Master, EtherNet/IP, USB, along with options for CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485. The PLC can handle a maximum of 192 remote I/O nodes and 40 expansion units via the CJ I/O Bus. Take the First Step with a Quote for your requirement of Omron PLC 20MB Program Capacity. Our commitment to better pricing and exceptional support sets us apart from other Competitors..
