S8JX-P60048N: Omron 600W 48V Standard Supply
Technical Specifications of Omron 600W 48V Standard Supply S8JX-P60048N:
| Spec | Value |
|---|---|
| Power Rating | 600 W |
| Output Voltage | 48 VDC |
| Connection | Terminal blocks |
| Terminal Type | Screw Terminal |
Omron 600W 48V Standard Supply S8JX-P60048N Technical Specifications:
| Specification | Value |
|---|---|
| Power rating | 600 W |
| Output voltage | 48 VDC |
| Connection | Terminal blocks |
| Terminal type | Screw Terminal |
| Mounting | Front mounting |
| Efficiency | 79% typ. (at 100 VAC input) 79% typ. (at 200 VAC input) |
| Rated input voltage | 100 to 240 VAC |
| Input Frequency | 50/60Hz (47 to 63 Hz) |
| Rated input current | 8.7 A max. (at 100 VAC input) 4.3 A max. (at 200 VAC input) |
| Input Leakage current | 0.5 mA max. (at 100 VAC input) 1.0 mA max. (at 200 VAC input) |
| Rated output current | 13 A |
| Output voltage variable range | ±10% (With V.ADJ) |
| Start-up time | 1000 ms typ. (at 100 VAC input) 1000 ms typ. (at 200 VAC input) |
| Hold time | 20 ms min. (at 100 VAC input) 20 ms min. (at 200 VAC input) |
| Output indicator | Yes (color: green) |
| Vibration resistance | 10 to 55 Hz, 0.375 mm single amplitude in each 3 directions for 2 hours |
| Shock resistance | 150 m/s2, in each 6 directions 3 times |
| Ambient temperature (Operating) | -10 to 70 ℃ |
| Ambient temperature (Storage) | -25 to 75 ℃ |
| Ambient humidity (OperatingStorage) | 25 to 85% |
| Cooling fan | Yes |
| Degree of protection | - |
| Weight | 1800 g max. |
Please speak to our Technical Engineer for Omron 600W 48V Standard Supply, S8JX-P60048N with exclusive offers. In-depth Technical Analysis of S8JX-P60048N includes 600 W, 48 VDC, Terminal blocks, Screw Terminal, Front mounting, 79% typ. (at 100 VAC input)
79% typ. (at 200 VAC input), 100 to 240 VAC & 50/60Hz (47 to 63 Hz). Moreover, it features 8.7 A max. (at 100 VAC input)
4.3 A max. (at 200 VAC input), 0.5 mA max. (at 100 VAC input)
1.0 mA max. (at 200 VAC input), 13 A, ±10% (With V.ADJ), 1000 ms typ. (at 100 VAC input)
1000 ms typ. (at 200 VAC input), 20 ms min. (at 100 VAC input)
20 ms min. (at 200 VAC input), Yes (color: green), 10 to 55 Hz, 0.375 mm single amplitude in each 3 directions for 2 hours, 150 m/s2, in each 6 directions 3 times, -10 to 70 ℃, -25 to 75 ℃. Don't Miss Out on a Quote for your requirement of Omron 600W 48V Standard Supply. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
