KFD2-HLC-Ex1-D-2W: P&F 2 Relay Contact Transmitter Power Supplies
Technical Specifications of P&F 2 Relay Contact Transmitter Power Supplies KFD2-HLC-Ex1-D-2W:
| Spec | Value |
|---|---|
| Signa Type | Analog input |
| Rated Voltage | 19 ... 30 V DC |
| Dimensions | 40 x 119 x 115 mm (1.6 x 4.7 x 4.5 inch) |
| Connection | screw terminals |
P&F 2 Relay Contact Transmitter Power Supplies KFD2-HLC-Ex1-D-2W Technical Specifications:
| Specification | Value |
|---|---|
| Signal type | Analog input |
| Safety Integrity Level (SIL) | - |
| Systematic capability (SC) | - |
| Supply Connection | Power Rail or terminals 23+, 24- |
| Rated voltage | 19 ... 30 V DC |
| Ripple | - |
| Rated current | approx. 120 mA at 24 V DC |
| Power dissipation | 2.5 W |
| Power consumption | 3.1 W |
| Connection side (Input) | field side |
| Connection (Input) | terminals 1, 2, 3, 4, 5, 6 |
| Input signal | - |
| Open circuit voltage/short-circuit current (Input) | typ. 24 V / 28 mA |
| Input resistance | 250 Ω , 5 % (terminals 2, 3 and with jumper on 5, 6) |
| Available voltage | ≥ 15.5 V at 20 mA, short-circuit protected |
| Connection side (Output) | control side |
| Connection (Output) | output I: terminals 10, 11, 12, output II: terminals 16, 17, 18, output III: terminals 7, 8, 9, output IV: terminals 13, 14, 15, output V: terminals 19, 20, 21 |
| Load | max. 650 Ω , source mode |
| Output signal | analog |
| Frequency range | - |
| Settling time | - |
| Display elements | LEDs , display |
| Labeling | space for labeling at the front |
| Dimensions | 40 x 119 x 115 mm (1.6 x 4.7 x 4.5 inch) |
| Connection | screw terminals |
| Mounting | on 35 mm DIN mounting rail |
| Ambient temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Degree of protection | IP20 |
| Mass | 300 g |
Please speak to our Technical Engineer for P&F 2 Relay Contact Transmitter Power Supplies KFD2-HLC-Ex1-D-2W at attractive prices. Technical Specs Summary of 40 x 119 x 115 mm (1.6 x 4.7 x 4.5 inch) includes Analog input with - range, - and - ratings. Operating on 19 ... 30 V DC it consumes 2.5 W. The field side connects via input connection, terminals 1, 2, 3, 4, 5, 6, supporting up to max. 650 Ω , source mode. The control side includes output I: terminals 10, 11, 12, output II: terminals 16, 17, 18, output III: terminals 7, 8, 9, output IV: terminals 13, 14, 15, output V: terminals 19, 20, 21. It features a - settling time, and LEDs , display indicators. The unit measures 40 x 119 x 115 mm (1.6 x 4.7 x 4.5 inch), mounts on a 35mm DIN rail, and operates between -20 ... 60 °C (-4 ... 140 °F). With a an IP20 rating and approximately 300 g weight, it ensures reliable performance. Match Your Needs with a Quote for your requirement of P&F 2 Relay Contact Transmitter Power Supplies. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
