KFD2-SH-Ex1-T-OP: - P&F SIL 3 Switch Amplifiers with Conformal Coating
Technical Specifications of P&F SIL 3 Switch Amplifiers with Conformal Coating KFD2-SH-Ex1-T-OP:
| Spec | Value |
|---|---|
| Dimensions | 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) |
| Supply Connection | Power Rail or terminals 14+, 15- |
| Output | active voltage output, short-circuit proof, 0-signal: 0 V, 1-signal: 19 V DC at 15 mA ... 31 V DC at no-load, fault: 0 V |
| Connection | screw terminals , max. 2.5 mm3 |
P&F SIL 3 Switch Amplifiers with Conformal Coating KFD2-SH-Ex1-T-OP, Technical Specifications:
| Specification | Value |
|---|---|
| Signal type | Digital Input |
| Safety Integrity Level (SIL) | SIL 3 |
| Systematic capability (SC) | - |
| Supply Connection | Power Rail or terminals 14+, 15- |
| Rated voltage | 20 ... 30 V DC |
| Rated current | ≤ 100 mA |
| Power dissipation | 1.5 W |
| Power consumption | max. 1.7 W |
| Connection side (Input) | field side |
| Ripple | ≤ 10 % |
| Connection (Input) | terminals 4+, 6- |
| Open circuit voltage/short-circuit current (Input) | approx. 8.4 V DC / approx. 11.7 mA |
| Switching point/switching hysteresis (Input) | I < 2.1 mA and I > 5.9 mA , output switched off |
| Connection side (Output) | control side |
| Connection (Output) | output I: terminals 7+, 8- ; output II: terminals 9, 10 ; output III: terminals 11, 12 |
| Response time | - |
| Signal level | - |
| Output I | active voltage output, short-circuit proof, 0-signal: 0 V, 1-signal: 19 V DC at 15 mA ... 31 V DC at no-load, fault: 0 V |
| Output II | relay |
| Minimum switch current | - |
| Switching frequency | ≤ 50 Hz |
| Display elements | LEDs |
| Control elements | - |
| Dimensions | 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) |
| Connection | screw terminals , max. 2.5 mm3 |
| Mounting | on 35 mm DIN mounting rail |
| Ambient temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Degree of protection | IP20 |
Mail Us for P&F SIL 3 Switch Amplifiers with Conformal Coating KFD2-SH-Ex1-T-OP at unbeatable prices. Detailed Specifications of KFD2-SH-Ex1-T-OP, feature Digital Input signal type, Power Rail or terminals 14+, 15- supply connection, Digital Input rated voltage, ≤ 100 mA rated curent, field side input connection, -, response time, control side, output connection, active voltage output, short-circuit proof, 0-signal: 0 V, 1-signal: 19 V DC at 15 mA ... 31 V DC at no-load, fault: 0 V output, ≤ 50 Hz switching frequency, with dimensions of 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) screw terminals , max. 2.5 mm3 connection, on 35 mm DIN mounting rail mounting, -20 ... 60 °C (-4 ... 140 °F) ambient temperature IP20 degree of protection. Elevate Your Project with a Quote for your requirement of P&F SIL 3 Switch Amplifiers with Conformal Coating. Count on us for more economical pricing and more reliable support than other Traders & Suppliers.
