KFD2-STC4-Ex1-2O-H: P&F 2.5 W Consume Transmitter Power Supplies
Technical Specifications of P&F 2.5 W Consume Transmitter Power Supplies KFD2-STC4-Ex1-2O-H:
| Spec | Value |
|---|---|
| Signa Type | Analog input |
| Rated Voltage | 20 ... 35 V DC |
| Dimensions | 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch) |
| Connection | screw terminals |
P&F 2.5 W Consume Transmitter Power Supplies KFD2-STC4-Ex1-2O-H Technical Specifications:
| Specification | Value |
|---|---|
| Signal type | Analog input |
| Safety Integrity Level (SIL) | SIL 3 |
| Systematic capability (SC) | - |
| Supply Connection | Power Rail or terminals 14+, 15- |
| Rated voltage | 20 ... 35 V DC |
| Ripple | within the supply tolerance |
| Rated current | - |
| Power dissipation | 1.9 W |
| Power consumption | 2.5 W |
| Connection side (Input) | field side |
| Connection (Input) | terminals 1+, 2-, 3 or 5-, 6+ |
| Input signal | 0/4 ... 20 mA |
| Open circuit voltage/short-circuit current (Input) | terminals 1+, 3-: 24.2 V / 38 mA |
| Input resistance | terminals 2-, 3: max. 76 Ω, terminals 1+, 3: max. 500 Ω (250 Ω load) |
| Available voltage | terminals 1+, 3: ≥ 17.6 V at 20 mA |
| Connection side (Output) | control side |
| Connection (Output) | terminals 7-, 8+,9; 10-, 11+,12 |
| Load | 0 ... 550 Ω at 20 mA |
| Output signal | 0/4 ... 20 mA (overload > 25 mA) |
| Frequency range | field side into the control side: band width with 1 Vpp signal 0 ... 7.5 kHz (-3 dB), safe area to hazardous area: band width with 1 VSS signal 0.3 ... 7.5 kHz (-3 dB) |
| Settling time | 200 µs |
| Display elements | LED |
| Labeling | space for labeling at the front |
| Dimensions | 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch) |
| Connection | screw terminals |
| Mounting | on 35 mm DIN mounting rail |
| Ambient temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Degree of protection | IP20 |
| Mass | approx. 200 g |
Give Us a Call for P&F 2.5 W Consume Transmitter Power Supplies KFD2-STC4-Ex1-2O-H at the lowest pricing. In-depth Technical Analysis of 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch) feature Analog input with 0/4 ... 20 mA range, SIL 3 and - ratings. Operating on 20 ... 35 V DC it consumes 1.9 W. The field side connects via input connection, terminals 1+, 2-, 3 or 5-, 6+, supporting up to 0 ... 550 Ω at 20 mA. The control side includes terminals 7-, 8+,9; 10-, 11+,12. It features a 200 µs settling time, and LED indicators. The unit measures 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch), mounts on a 35mm DIN rail, and operates between -20 ... 60 °C (-4 ... 140 °F). With a an IP20 rating and approximately approx. 200 g weight, it ensures reliable performance. Elevate Your Project with a Quote for your requirement of P&F 2.5 W Consume Transmitter Power Supplies. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
