Home / Products / Proximity Sensor / Pepperl Fuchs / NBB1-3M22-E2
Pepperl Fuchs Inductive Sensors
NBB1-3M22-E2
Are you in search of NBB1-3M22-E2 Pepperl Fuchs Inductive Sensor that meets your specific needs? Look no further than Challaturu Automation, where we offer a range of options including a 1 mm rated operating distance, PNP output, and flush type.
NBB1-3M22-E2 Technical Specifications:
| Switching function | Normally open (NO) | |
| Output type | PNP | |
| Rated operating distance | 1 mm | |
| Installation | flush | |
| Output polarity | DC | |
| Output type | 3-wire | |
| Operating voltage | 10 … 30 V | |
| Switching frequency | 0 … 700 Hz | |
| Switching state indicator | LED, yellow | |
| Ambient temperature | -25 … 70 °C (-13 … 158 °F) | |
| Connection type | Cable PUR , 2 m | |
| Housing material | Stainless steel 1.4305 / AISI 303 | |
| Sensing face | PC | |
| Degree of protection | IP67 | |
Product Documentation: NBB1-3M22-E2
Related Products: NBB1-3M22-E2
NBB8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1350 Hz, Output type: 3-wire, Construction type: Not specified, Sensor length: 24mm x 24mm x 1mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 5-36V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB8-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1350 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB0 6-4GM22-E2
Inductive Proximity Sensor, Rated operating distance: 0.6 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1400 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB1 5-4M25-E2
Inductive Proximity Sensor, Rated operating distance: 1.5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 3000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB10-30GM40-Z0-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 150 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1 , 4-pin, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plated, Degree of protection: IP67.
NBN8-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB2-12GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: 4-pin M12 x 1 connector, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB15-30GM50-E2-M
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 600 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plating, Degree of protection: IP68/IP69K.
NBB10-30GM60-A2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 1100 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB0 6-3M22-E2
Inductive Proximity Sensor, Sensor diameter: 0.6mm, Rated operating distance: 0.6 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1400 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB1-5-8GM40-Z0
Inductive Proximity Sensor, Sensor diameter: Not specified, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 1200 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 60 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB4-12GM50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Construction type: Cylindrical thread, Sensor length: 50mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 10-30V, Housing material: PBT, Degree of protection: IP68
NBB15-30GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB1-4GM22-E2
Inductive Proximity Sensor, Rated operating distance: 1 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 700 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB10-30GM40-Z0-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 150 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1 , 4-pin, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plated, Degree of protection: IP67.
The operating voltage range is between 10 to 30 V with a switching frequency of 0 to 700 Hz. A yellow LED serves as the switching state indicator. It can function in temperatures ranging from -25 to 70 °C (-13 to 158 °F) and is equipped with a 2 m PUR cable for connection. The housing material is made of stainless steel 1.4305 / AISI 303 and the sensing face is constructed from PC. It also has an IP67 degree of protection. Contact Challaturu Automation today to find the best Proximity Sensor that meets your needs.
