Pepperl + Fuchs Inductive Proximity Sensor NBB10-30GM50-E2-C-V1
The Technical specifications of NBB10-30GM50-E2-C-V1:
Sensor Head: M30
Switching function: Normally open (NO)
Output type: PNP
operating distance: 10 mm
Installation: flush
Output type:3-wire
Operating voltage:10 … 30 V DC
Switching frequency: 0 … 10 Hz
Connection type: Connector plug M12 x 1 , 4-pin
NBB10-30GM50-E2-C-V1 Technical Specifications:
| Switching function | Normally open (NO) | |
| Output type | PNP | |
| Rated operating distance | 10 mm | |
| Installation | flush | |
| Output polarity | DC | |
| Assured operating distance | 0 … 8.1 mm | |
| Reduction factor rAl | 0.3 | |
| Reduction factor rCu | 0.2 | |
| Reduction factor r304 | 0.6 | |
| Output type | 3-wire | |
| Operating voltage | 10 … 30 V DC | |
| Switching frequency | 0 … 10 Hz | |
| Hysteresis | typ. 5 % | |
| Reverse polarity protection | reverse polarity protected | |
| Short-circuit protection | pulsing | |
| Voltage drop | ≤ 3 V | |
| Operating current | 0 … 200 mA | |
| Off-state current | 0 … 0.5 mA typ. 0.1 µA at 25 °C | |
| No-load supply current | ≤ 17 mA | |
| Constant magnetic field | 100 mT | |
| Alternating magnetic field | 100 mT | |
| Switching state indicator | Multihole-LED, yellow | |
| MTTFd | 1835 a | |
| Mission Time (TM) | 20 a | |
| Diagnostic Coverage (DC) | 0 % | |
| Operation indicator | 4-way dual LED Green: power Yellow: output |
|
| Standard conformity-Standards | EN 60947-5-2:2007 EN 60947-5-2/A1:2012 IEC 60947-5-2:2007 IEC 60947-5-2 AMD 1:2012 |
|
| CCC approval | CCC approval / marking not required for products rated ≤36 V | |
| UL approval | cULus Listed, General Purpose | |
| CSA approval | cCSAus Listed, General Purpose | |
| Ambient temperature | -25 … 70 °C (-13 … 158 °F) | |
| Connection type | Connector plug M12 x 1 , 4-pin | |
| Core cross section | – | |
| Housing material | Brass, PTFE coated | |
| Sensing face | PPS | |
| Degree of protection | IP67 | |
