Pepperl Fuchs Inductive Sensor NBB15-30GM50-WS
NBB15-30GM50-WS Technical Specifications:
Challaturu provides the Pepperl Fuchs Proximity Sensor NBB15-30GM50-WS that satisfies your industrial requirements with an M30, Flush type, cable, NO, 3-wire output, and a sensing distance of 15mm.
| Sensor Head | M30 | |
| Switching function | Normally Open (NO) | |
| Output type | PNP | |
| Rated operating distance | 15 mm | |
| Installation | Quasi Flush | |
| Output polarity | AC | |
| Assured operating distance | 0 … 12.15 mm | |
| Output type | 2-wire | |
| Operating voltage | 20 … 253 V | |
| Switching frequency | 0 … 20 Hz | |
| Ambient temperature | -25 … 70 °C (-13 … 158 °F) | |
| Connection type | cable PVC, 2 m | |
| Housing material | brass, white bronze coated | |
| Sensing face | PBT | |
| Degree of protection | IP67 | |
Product Documentation: NBB15-30GM50-WS
Related Products: NBB15-30GM50-WS
NBN8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB0 8-5GM25-E2
Inductive Proximity Sensor, Rated operating distance: 0.8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 3000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB1 5-4M25-E2
Inductive Proximity Sensor, Rated operating distance: 1.5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 3000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB1 5-F79-E0
Inductive Proximity Sensor Rated operating distance: 1.5 mm Switching function: Normally open (NO) Output type: NPN Installation: Flush Switching frequency: 0 … 1200 Hz Output type: 3-wire Type of voltage: DC Connection type: Flexible leads PVC, 500 mm Operating voltage: 5 … 30 V DC Housing material: PA Degree of protection: IP67
NBB8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1350 Hz, Output type: 3-wire, Construction type: Not specified, Sensor length: 24mm x 24mm x 1mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 5-36V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB1-4GM22-E2
Inductive Proximity Sensor, Rated operating distance: 1 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 700 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB1-5-5GM25-E2
Inductive Proximity Sensor, Rated operating distance: 1.5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 3000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBN3-8GM25-E2-V3
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 3 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 4500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M8 x 1 , 3-pin, Operating voltage: 5 … 30 V, Housing material: Brass, nickel-plated, Degree of protection: IP67.
NBN3-8GM30-E2
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 3 mm, Switching function: Normally open (NO), Output type: PNP, Installation: non-flush, Switching frequency: 0 … 4500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 30 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBN3-8GM30-E2-V1
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 3 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 4500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1 , 4-pin, Operating voltage: 5 … 30 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBN3-F31-E8-K
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 3 mm, Switching function: 2 x normally open (NO), Output type: PNP, Installation: flush mountable, Switching frequency: 0 … 500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: PVC cable 5 m, Operating voltage: 10 … 30 V DC, Housing material: PBT, Degree of protection: IP67.
NBN4-12GK50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1200 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: PBT, Degree of protection: IP68 / IP69K.
NBN4-12GM40-E0
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM40-E2
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM40-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
Challaturu offers Pepperl Fuchs NBB15-30GM50-WS is an inductive proximity switch sensor head with an M30 form factor. It has a Normally Open (NO) switching function and a PNP output type, making it suitable for a variety of industrial applications.
The sensor has a rated operating distance of 15 mm and is installed in a quasi-flush manner. The output polarity of the sensor is AC, and it has an assured operating distance of 0 to 12.15 mm. The sensor’s output type is 2-wire, and it operates at a voltage range of 20 to 253 V, with a switching frequency of 0 to 20 Hz.
It has a wide operating temperature range of -25 to 70°C (-13 to 158°F), making it suitable for use in harsh environments. The sensor is connected via a 2-meter-long PVC cable and is housed in a durable brass material with a white bronze coating. The sensing face of the sensor is made of PBT material and has a degree of protection of IP67, which ensures protection against dust and water.
Pepperl Fuchs NBB15-30GM50 WS is a high-quality inductive proximity switch sensor head suitable for use in various industrial applications. It is manufactured by P&F, a reputable company that produces high-quality inductive/capacitive sensors.
