Pepperl Fuchs Proximity Sensor NBB2-12GM50-E2-V1
The technical specifications of the NBB2-12GM50-E2-V1 are summarized as follows:
- Housing diameter: 12mm
- Switching function: Normally Open (NO)
- Output type: PNP
- Rated operating distance: 2mm
- Installation: Flush
- Connection type: 4-pin Connector M12 x 1
- Housing material: Brass with a nickel plating
- Operating voltage: 10 to 30V
Technical Specifications of NBB2-12GM50-E2-V1
Pepperl Fuchs NBB2-12GM50-E2-V1 inductive proximity switch with 4 pins, 2mm sensing distance, flush installation, PNP output type, NO switching function, 3-wire output type, and an M12 connection type.
| Switching function | Normally open (NO) | |
| Output type | PNP | |
| Rated operating distance | 2 mm | |
| Installation | flush | |
| MTTFd | 1060 a | |
| Mission Time (TM) | 20 a | |
| Diagnostic Coverage (DC) | 0 % | |
| Ambient temperature | -40 … 70 °C (-40 … 158 °F) | |
| Connection type | Connector M12 x 1 , 4-pin | |
| Housing material | brass, nickel-plated | |
| Sensing face | PBT | |
| Housing diameter | 12 mm | |
| Degree of protection | IP67 | |
| Scope of delivery | 2 self locking nuts in scope of delivery | |
| Output polarity | DC | |
| Assured operating distance | 0 … 1.62 mm ( -25 … 70 °C (-13 … 158 °F) ) 0 … 1.52 mm ( -40 … -25 °C (-40 … -13 °F) ) |
|
| Reduction factor rAl | 0.3 | |
| Reduction factor rCu | 0.2 | |
| Reduction factor r304 | 0.7 | |
| Operating voltage | 10 … 30 V | |
| Switching frequency | 0 … 1500 Hz | |
| Reverse polarity protection | reverse polarity protected | |
| Short-circuit protection | pulsing | |
| Voltage drop | ≤ 3 V | |
| Operating current | 0 … 200 mA | |
| Off-state current | 0 … 0.5 mA typ. 0.1 µA at 25 °C | |
| No-load supply current | ≤ 17 mA | |
| Switching state indicator | Multihole-LED, yellow | |
Product Documentation: NBB2-12GM50-E2-V1
Here is the main technical specification of Pepperl Fuchs Inductive Proximity Sensor NBB2-12GM50-E2-V1: M12 Dia, Flush, 2mm Sensing, Normally Open, PNP, Cable type.
If you want to know all range Pepperl Fuchs proximity models you can check.
