Pepperl + Fuchs Inductive Sensors NBB4-12GM50-A2-V1
NBB4-12GM50-A2-V1 Technical Specifications:
IndMALL Automation offers the ideal solution for your industrial needs if you require a P&F proximity sensor with an M12 dia, 4mm, PNP, complementary, M12 Connector, with 4-pin and flush type the Pepperl Fuchs NBB4-12GM50-A2-V1 sensor.
| Sensor Head | M12 | |
| Switching function | complementary | |
| Output type | PNP | |
| Rated operating distance | 4 mm | |
| Installation | flush | |
| Output Type | 4-wire | |
| Operating voltage | 5 … 36 V | |
| Switching frequency | 0 … 2550 Hz | |
| Switching state indicator | Multihole-LED, yellow | |
| Ambient temperature | -40 … 85 °C (-40 … 185 °F) | |
| Connection type | Connector plug | |
| Housing material | brass, white bronze coated | |
| Sensing face | PBT, Green | |
| Degree of protection | IP68 | |
| Connector Threading | M12 x 1 | |
| Connector Number of pins | 4 | |
Product Documentation: NBB4-12GM50-A2-V1
Related Products: NBB4-12GM50-A2-V1
NBB2-12GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: 4-pin M12 x 1 connector, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB2-12GM40-Z0-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 1000 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1 , 4-pin, Operating voltage: 5 … 60 V, Housing material: Brass, nickel-plated, Degree of protection: IP67.
NBB2-12GM50-A2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 2 mm, Switching function: Complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 3500 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB2-12GM50-E0
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 3500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN3-8GM50-E2
Inductive Proximity Sensor, Sensor diameter: M8, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 4500 Hz, Output type: 3-wire, Sensor length: Not specified, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 5-30V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
Pepperl Fuchs is a renowned manufacturer of proximity sensors, including inductive and capacitive sensors. One of their products, the NBB4-12GM50-A2-V1, is a highly reliable and versatile sensor that features the following technical specifications:
The sensor head of the NBB4-12GM50-A2-V1 is an M12 type, and the switching function is complementary. This means that when the sensor detects an object, the output signal switches from one state to the other. The output type of the sensor is PNP, which stands for “positive-negative-positive.”
The rated operating distance for the sensor is 4 mm, and it is designed to be installed flush with the mounting surface. The output type is 4-wire, and the sensor can operate within a voltage range of 5 to 36 V, with a switching frequency of 0 to 2550 Hz. The sensor also features a multihole-LED, yellow switching state indicator, which enables easy monitoring of its status.
The ambient temperature range for the sensor is -40 to 85 °C (-40 to 185 °F), making it ideal for use in a wide range of industrial applications. The P&F proximity Switch NBB4-12GM50-A2-V1 has a connector plug connection type, and the housing material is made of brass that is white bronze coated. The sensing face of the sensor is made of green PBT (polybutylene terephthalate), which is a type of thermoplastic material.
The degree of protection for the sensor is IP68, which means that it is highly resistant to dust and water ingress. The connector threading of the NBB4-12GM50-A2-V1 is M12 x 1, and it has 4 pins.
