Pepperl Fuchs Inductive Sensor NBB4-12GM50-E2-V1-M
NBB4-12GM50-E2-V1-M Technical Specifications:
If you’re in need of an M12 dia with a 4mm, NO output, and a flush, Connector plug M12 x 1, 3-pin Sensor, Challaturu has you covered with the NBB4-12GM50-E2-V1-M P&F Inductive sensor.
| Switching function | Normally open (NO) | |
| Housing diameter | 12 mm | |
| Output type | PNP | |
| Rated operating distance | 4 mm | |
| Installation | flush | |
| Output polarity | DC | |
| Output type | 3-wire | |
| Operating voltage | 5 … 60 V | |
| Switching frequency | 0 … 2500 Hz | |
| Switching state indicator | LED, yellow | |
| Connection type | Connector plug M12 x 1, 3-pin | |
| Housing material | brass, nickel-plated | |
| Sensing face | PBT | |
| Degree of protection | IP68 / IP69K | |
Product Documentation: NBB4-12GM50-E2-V1-M
Related Products: NBB4-12GM50-E2-V1-M
NBB8-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1350 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB10-30GM40-Z0-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 150 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1 , 4-pin, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plated, Degree of protection: IP67.
NBB10-30GM50-E2-C-V1
Inductive Proximity Sensor Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 10 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1, Operating voltage: 10 … 30 V DC, Housing material: Brass with PTFE coating, Degree of protection: IP67.
NBB10-30GM50-WS
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 20 Hz, Type of voltage: AC, Connection type: Cable, Operating voltage: 20 … 253 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
Pepperl Fuchs is a leading manufacturer of proximity sensors, inductive sensors, and capacitive sensors, with a range of high-quality products designed to meet industrial sensing needs. One such product is the Pepperl Fuchs NBB4-12GM50-E2-V1-M is a device with a normally open (NO) switching function and a housing diameter of 12 mm. Its output type is PNP, and it has a rated operating distance of 4 mm. The device is designed for flush installation and has a DC output polarity. Its output type is 3-wire, and it operates with a voltage range of 5 to 60 V.
The switching frequency of the device ranges from 0 to 2500 Hz, and it has a yellow LED switching state indicator. The device comes with a 3-pin connector plug of M12 x 1 type for the connection. The housing of the device is made of brass and nickel-plated, while the sensing face is made of PBT material. The device has a degree of protection of IP68 / IP69K, making it resistant to dust and water ingress. For Standard Cable type requirements you can Check NBB4-12GM50-E2
