Pepperl Fuchs Inductive Sensors
NBB5-18GM60-WO
Challaturu Automation has got your back with the Pepperl Fuchs NBB5-18GM60-WO Proximity Sensor that has a 5mm sensing distance, NC switching function, AC output polarity, two-wire output, flush-type, and NO switching function.
NBB5-18GM60-WO Technical Specifications:
| Switching function | Normally closed (NC) | |
| Output type | two – wire | |
| Rated operating distance | 5 mm | |
| Installation | flush | |
| Output polarity | AC | |
| Operating voltage | 20 … 253 V | |
| Switching frequency | 0 … 20 Hz | |
| Connection type | cable PVC, 2 m | |
| Housing material | brass, nickel-plated | |
| Sensing face | PBT | |
| Degree of protection | IP67 | |
Product Documentation: NBB5-18GM60-WO
Related Products: NBB5-18GM60-WO
NBB5-18GM40-Z0
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 500 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBN8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB1 5-4M25-E2
Inductive Proximity Sensor, Rated operating distance: 1.5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 3000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67.
NBB10-30GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1100 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM50-US
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 30 Hz, Output type: 2-wire, Type of voltage: AC/DC, Connection type: Cable, Operating voltage: 20 … 250 V AC/20 … 300 V DC, Housing material: Brass, nickel-plated, Degree of protection: IP67.
NBB2-12GM50-E0
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 3500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB2-8GM30-E0
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 6000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable PVC, 2 m, Operating voltage: 5 … 30 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBB20-L2-A2-V1
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 20 mm, Switching function: complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 440 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1 , 4-pin, Operating voltage: 10 … 30 V DC, Housing material: PA, Degree of protection: IP68 / IP69K.
NBB4-12GM30-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB4-12GM30-E2-V3
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M8 x 1 , 3-pin, Operating voltage: 10 … 30 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBN4-12GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN8-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB2-8GM40-E2-V3
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 6000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M8 x 1 , 3-pin, Operating voltage: 5 … 30 V, Housing material: Brass, nickel-plated, Degree of protection: IP67.
NBB4-12GM50-E2-M
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 2500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable (2m, 3 x 0.75 mm2, PUR cable), Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plating, Degree of protection: IP68 / IP69K.
NBB2-V3-E2
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V DC, Housing material: PBT, Degree of protection: IP67.
Challaturu Automation has a solution for your proximity sensing needs with the Pepperl Fuchs NBB5-18GM60-WO Proximity Sensor. This sensor has a rated operating distance of 5mm and a flush installation design. It features a normally closed switching function and an AC output polarity, with a two-wire output configuration.
The sensor has a switching frequency of 0 to 20 Hz and an operating voltage range of 20 to 253 V. The connection type is a 2-meter PVC cable, and the housing material is made of brass with nickel plating. The sensing face is constructed from PBT, and the degree of protection is IP67, ensuring the sensor can withstand harsh environments.
The Pepperl Fuchs Inductive Sensor from Challaturu Automation is a reliable and durable solution that can accurately detect objects at a close range with its 5mm sensing distance, and its NC switching function ensures safe and efficient operations.
You can check P&F 5mm series with cable type.
