Pepperl Fuchs Proximity Switch
NBB8-18GM60-US
Looking for the perfect industrial solution? Look no further than Challaturu Automation’s P&FNBB8-18GM60-US Proximity Sensor. These switches boast an 8mm rated operating distance, flush installation, PNP & 3 wire output to meet your industrial requirements.
NBB8-18GM60-US Technical Specifications:
| Switching function | Normally open (NO) | |
| Rated operating distance | 8 mm | |
| Installation | Flush | |
| Output Type | 2-wire | |
| Output polarity | DC | |
| Operating voltage | 20 … 250 V AC/20 … 300 V DC | |
| Switching frequency | 30 Hz | |
| Switching state indicator | LED, yellow | |
| Ambient temperature | -25 … 70 °C (-13 … 158 °F) | |
| Connection type | cable PUR, 2 m | |
| Housing material | brass, nickel-plated | |
| Sensing face | PBT | |
| Degree of protection | IP67 | |
Product Documentation: NBB8-18GM60-US
Related Products: NBB8-18GM60-US
NBN8-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB5-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1950 Hz, Output type: 3-wire, Construction type: Cylindrical thread, Rated operating distance: 5 mm, Type of voltage: DC, Connection type: Connector plug, Operating voltage: DC 5-36V, Housing material: Brass, white bronze coated, Sensing face: PBT, green, Degree of protection: IP68.
NBN4-12GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB4-12GM30-E3-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally closed (NC), Output type: PNP, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB3-V3-Z4
Inductive Proximity Sensor, Rated operating distance: 3 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 2000 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 60 V, Housing material: PBT, Degree of protection: IP67.
NBB2-8GH40-E2-V3
Inductive Proximity Sensor, Sensor diameter: M8, Rated operating distance: 2 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 6000 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M8 x 1, 3-pin, Operating voltage: 5 … 30 V, Housing material: Stainless steel 1.4404 / AISI 316L, Degree of protection: IP67.
NBB8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1350 Hz, Output type: 3-wire, Construction type: Not specified, Sensor length: 24mm x 24mm x 1mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 5-36V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM50-E2
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB10-30GM50-E2-C-V1
Inductive Proximity Sensor Rated operating distance: 10 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 10 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M12 x 1, Operating voltage: 10 … 30 V DC, Housing material: Brass with PTFE coating, Degree of protection: IP67.
NBB15-30GM50-E0
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB15-30GM50-WS
Inductive Proximity Sensor, Sensor diameter: M30, Rated operating distance: 15 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Quasi flush, Switching frequency: 0 … 20 Hz, Output type: 2-wire, Type of voltage: AC, Connection type: Cable, Operating voltage: 20 … 253 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBB4-12GM50-A2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB5-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1950 Hz, Output type: 3-wire, Construction type: Cylindrical thread, Rated operating distance: 5 mm, Type of voltage: DC, Connection type: Connector plug, Operating voltage: DC 5-36V, Housing material: Brass, white bronze coated, Sensing face: PBT, green, Degree of protection: IP68.
NBB8-18GM30-E3-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally closed (NC), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1350 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB8-18GM60-US
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 30 Hz, Output type: 2-wire, Type of voltage: AC/DC, Connection type: Cable, Operating voltage: 20 … 250 V AC/20 … 300 V DC, Housing material: Brass with nickel-plating, Degree of protection: IP67.
If you’re looking for the perfect industrial solution, look no further than Challaturu Automation’s P&F NBB8-18GM60-US Proximity Sensor. These switches offer an 8mm rated operating distance, flush installation, and PNP & 3 wire output to meet your industrial requirements.
The Inductive Proximity Switches have a normally open (NO) switching function and a 2-wire output type with a DC output polarity. It has an operating voltage range of 20 to 250V AC or 20 to 300V DC and a switching frequency of 30Hz. The switch also features a yellow LED switching state indicator, making it easy to monitor its operation.
This P&F proximity switch is built with high-quality materials, including nickel-plated brass housing and a PBT sensing face. It has an IP67 degree of protection, making it suitable for use in harsh environments. The NBB8-18GM60-US comes with a 2m cable PUR connection and can operate in temperatures ranging from -25 to 70°C (-13 to 158°F).
Overall, the P&F Proximity Sensor is an excellent choice for industrial applications that require accurate and reliable sensing in challenging environments.
You can check P&F 8mm series with cable type.
